FEFCO 0860

Hexagonal Display Pedestal with Heavy-Duty Shelf

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Two-piece construction featuring a factory-glued hexagonal base and a drop-in shelf
  • Floor-length internal legs provide high vertical weight capacity
  • Ships flat to the store and requires manual, two-handed assembly

About this product

A freestanding, six-sided corrugated retail fixture designed to present merchandise at eye level. Unlike standard dump bins that rely on weak wall tabs, this pedestal uses a separate drop-in shelf with legs that extend all the way to the floor, transferring heavy product weight directly to the ground.

Because the internal support structure requires a large second sheet of corrugated board, this display focuses entirely on vertical strength. It makes sense when you are merchandising heavy liquids, hardware, or premium goods that would crush a standard false-floor bin.

Common uses

  • Liquor and beverage promotions
  • Heavy cosmetics and personal care
  • Hardware bulk bins
  • Premium single-item pedestals

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Merchandising and Heavy Payload Displays

Heavy bulk promotions

For items like bottled beverages, large cosmetics, or hardware, the floor-supported shelf prevents the center from sagging or tearing out under concentrated weight.

Premium single-item pedestals

The six-sided pillar provides a clean, architectural staging area for high-value electronics or seasonal centerpieces, with continuous 360-degree branding.

Center-aisle promotional islands

The freestanding hexagonal footprint allows shoppers to approach the display from any direction, making it effective for open floor spaces.

High-traffic retail dump bins

The rigid base and floor-length internal legs ensure the display remains stable even when shoppers lean in or dig through dense inventory.

Product Categories and Store Environments

Beverage and liquor rollouts

Glass bottles quickly exceed the weight limits of standard corrugated bins. The internal floor-length legs safely support heavy payloads in center-aisle promotional spots.

Hardware and home improvement

Dense, loose items like packaged tools or heavy fittings require a rigid base that resists buckling under uneven weight distribution.

Automotive supplies

Heavy oil jugs and dense parts demand a floor-supported load path to prevent the display shelf from collapsing during a multi-week promotion.

When to Consider Lighter Dump Bins

Merchandising lightweight goods

If you are packing plush toys, snacks, or apparel, a tab-supported false floor uses much less corrugated board and saves material.

Separating multiple SKUs

If you need to present different product lines rather than dumping them into a single deep bin, a multi-tray display provides distinct vertical shelves.

Close variants and lookalike dielines

The closest library neighbors include 0858, 0859, EVC92031. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board Selection, Print, and Assembly Planning

Board grade and wall splay

The hexagonal base requires a rigid board to prevent the walls from bulging outward under radial pressure. However, overly thick double-wall board can make sliding the large insert into the tube difficult.

Shelf depth and product volume

The depth of the recessed shelf dictates how much inventory the bin holds. A deeper shelf means shorter internal legs, but the load path always transfers directly to the floor.

Print coverage and finish

The continuous six-sided tube provides a large canvas for retail branding. You must plan artwork that wraps cleanly around the 60-degree corners.

Pack-station labor planning

Store staff must manually fold the six long legs of the insert and slide it down into the tube. This two-handed process takes more time than popping open a simple square bin.

Adjusting the Display Proportions

Shelf elevation

The distance from the top rim to the display floor can be adjusted to match the height of your specific product, ensuring items remain visible without falling out.

Base corner angles

While a true hexagon uses 60-degree corners, the footprint can be stretched into an elongated hexagon to fit narrower retail aisles while maintaining the same two-piece support logic.

Insert leg length

The length of the folded support legs is tied directly to the shelf depth. These legs must always reach the floor to maintain the structural load path.

Board and packing details

Assembly friction and store labor

Because the insert features six long, folded legs, store staff must carefully align and slide it down into the hexagonal tube. This is a two-handed process that requires more care than setting up a simple square bin.

Flatbed die-cutting requirements

The floor-length legs mean the insert blank is a large cross-shape. This requires large flatbed die-cutting, making this display better suited for planned retail programs rather than short-run tests.

Base and Shelf Variations

Shelf Depth (ShD)

The internal shelf can be set shallow for single-layer premium presentations or deep for high-volume bulk merchandise.

Additional notes

Insert sliding friction

If the board is too thick or the insert flanges splay outward, the shelf can jam while sliding down the long hexagonal tube. Physical prototypes help verify this clearance before a full rollout.

Related Floor Displays

0859: Related template 0859

Nearby FEFCO style to review if the buyer wants a similar job but the closure, flap overlap, wall build, or part count changes the package choice.

EVC92031: Hexagonal Recycle Bin

EngView neighbor that can look close in CAD. Review it if a sample or dieline seems similar, then verify closure style, slots, wall build, and assembly before treating it as a substitute.

FAQs

Assembly and Store Operations

How does the store staff assemble this display?

The base ships as a flattened, glued tube. Staff push it open into a hexagon, manually fold the six long legs of the shelf insert downward, and slide the entire insert into the top of the tube until it rests on the floor.

Payload and Strength

Why does this hold more weight than a standard dump bin?

Instead of resting the shelf on small corrugated tabs cut into the walls, this display uses a separate insert with legs that reach all the way to the ground. The product weight transfers directly to the floor.

Shipping and Fulfillment

Can this display be shipped with the product already inside?

No. This is a multi-piece architectural display that ships knocked-down flat. It must be assembled and loaded at the retail store or by a co-packing facility.

Manufacturing and Cost

Why is this display more expensive to produce than a square bin?

It requires much more material. The internal legs effectively create a second set of walls inside the base. It also requires large flatbed die-cutting and specialized six-crease factory gluing.

Board and Finish

What board grade fits the base and insert?

A rigid single-wall board is usually a practical balance. It provides enough column strength to prevent the walls from bulging, while remaining thin enough to let the insert slide into place without jamming.

Design and Branding

Can all six sides of the base be printed?

Yes. The continuous hexagonal tube provides an unbroken 360-degree canvas for retail branding, making it effective for center-aisle placements.

Board and Finish

Can we use double-wall board for extra strength?

Usually not. While double-wall board increases vertical strength, it also increases friction. The thick board can cause the large folded insert to jam tightly inside the tube during assembly.

Assembly and Store Operations

Does the shelf require tape or glue to stay in place?

No. The shelf insert relies entirely on gravity and its floor-length folded legs to lock into position. Once the legs hit the floor, the shelf is fully supported.
