FEFCO 0861

Beveled Retail Display Pedestal

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • One-piece construction with a factory-glued side seam for fast store setup
  • Four main panels and four beveled corners provide a continuous graphic surface
  • Flat top cap supports lightweight items or secondary countertop displays

About this product

A freestanding corrugated column designed for retail advertising and point-of-sale staging. It features four main branding panels separated by beveled corners, creating a distinct architectural shape without requiring a multi-piece kit.

Because the side seam is glued before delivery, the pedestal ships flat and squares up quickly at the store. Retail staff fold and interlock the top and bottom caps to lock the beveled profile in place.

Common uses

  • Freestanding promotional totems for aisle ends.
  • Bases for lightweight cosmetic or confectionery trays.
  • Directional signage columns for trade shows.
  • Aisle-end boundary markers.

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Staging and Floor Advertising

Freestanding advertising totems

The tall panels act as a wraparound billboard. The beveled corners add structural rigidity and a premium visual edge compared to a standard square box, keeping it highly visible in open retail aisles.

Bases for lightweight countertop displays

The flat top cap provides a staging area for small product trays, ballot boxes, or cosmetic testers that need to be elevated to eye level. This turns a printed column into a functional product stand.

Directional signage columns

The four-sided visibility makes this column useful for wayfinding at trade shows or large events. Attendees can read the panels from multiple approach angles.

Aisle-end boundary markers

Placed at the edges of a promotional zone, these pedestals define a branded space without blocking sightlines to the actual merchandise on the shelves behind them.

Campaign Rollouts and Event Marketing

National retail campaigns

The one-piece construction simplifies distribution. Stores receive a single flat unit rather than a multi-piece kit, reducing the chance of lost parts in the backroom and speeding up floor deployment.

Trade shows and events

The pedestals pack flat for transport and assemble on-site without tape or tools. They work well for temporary directional signage, product podiums, or branded boundary markers.

Pop-up shops and temporary retail

Brands setting up short-term spaces rely on these columns to establish a physical presence quickly. At the end of the lease, the columns fold back down for recycling or transport.

When to Consider a Different Pedestal

Heavy bulk product presentation

If you need to hold loose merchandise, a dump bin with a suspended floor is a better choice than resting weight on a flat, unbraced pedestal cap. Look at an octagonal dump bin instead.

Extreme top loads

If the pedestal must support heavy electronics or large liquid containers, a multi-piece design with a dedicated drop-in weight-bearing base handles the stress better than modifying this one-piece structure.

Close variants and lookalike dielines

The closest library neighbors include EVC92032, 0850, 0852. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board Choice, Print Layout, and Top-Load Capacity

Internal support for heavier items

The standard top cap spans the width of the column without center bracing. If you plan to place products directly on top, discuss adding a separate die-cut internal cross to prevent the surface from sagging.

Board thickness versus foldability

Heavy flutes increase the vertical strength of the tall panels, but they also make the top and bottom interlocking tabs harder to fold by hand. A balance must be struck between column rigidity and assembly effort.

Print surface and graphic layout

The eight-panel continuous tube allows for wraparound graphics. Artwork should account for the creases at the beveled edges to ensure logos or critical text do not break awkwardly across a fold.

Base footprint and floor space limits

Adjusting the bevel width changes the overall footprint of the display. A wider bevel creates a more octagonal shape that takes up more floor space, while a narrow bevel keeps the profile closer to a standard square.

Adjusting the Bevel Profile and Column Height

Bevel width and angle

The severity of the chamfered corners can be adjusted. A wider bevel creates a more octagonal footprint, while a narrow bevel keeps the focus on the four main graphic panels.

Column height and mid-span stability

Taller columns increase the risk of the side walls bowing outward under their own weight or a top load. If the height increases significantly, a thicker board grade becomes necessary to maintain straight walls.

Top cap reinforcement inserts

While the pedestal is a single piece, a separate corrugated cross can be cut to drop inside the tube before the top cap is closed, providing a rigid center post for heavier display items.

Board and packing details

Squaring the eight-panel tube

Because the tube has eight creases rather than the standard four, it requires a deliberate push on opposite edges to pop open into the correct beveled shape before the end caps are locked.

Additional notes

Manual assembly requirements

The pack station or retail staff must manually square the eight-crease tube and sequence the folding of multiple top and bottom cap flaps. This cannot be erected by automated machinery.

Related Floor Displays

EVC92032: Hexagonal Recycle Bin

EngView neighbor that can look close in CAD. Review it if a sample or dieline seems similar, then verify closure style, slots, wall build, and assembly before treating it as a substitute.

0852: Related template 0852

Nearby FEFCO style to review if the buyer wants a similar job but the closure, flap overlap, wall build, or part count changes the package choice.

FAQs

Product Fit and Loading

Can this pedestal hold heavy products on top?

The standard flat top is unbraced in the center. For heavy items, an internal corrugated support cross should be added to prevent the cap from sagging or collapsing under the weight.

Assembly and Packing

Does the store need tape to build this?

The main tube is glued before delivery, so tape is generally unnecessary for assembly. Store staff square the column and fold the top and bottom flaps inward, where they interlock to hold the shape.

Board and Finish

How does board thickness affect the display?

Thicker board prevents the tall side walls from bowing, but it makes the interlocking end caps stiffer and harder to fold. Fine flutes offer cleaner folds and better print surfaces for smaller countertop versions.

Modifications

Can the angle of the corners be changed?

The template allows adjustments to the bevel width. This changes how sharp or soft the corners appear on the retail floor and alters the overall footprint of the display.

Shipping and Route

Does this ship flat?

Despite forming an eight-sided tube, the pedestal folds completely flat for transit. It is usually packed inside a master shipper for delivery to the retail store or event space.

Product Fit and Loading

Is this suitable for outdoor events?

Standard corrugated board absorbs moisture from the ground and humid air. For outdoor use, specific coatings or alternative materials would need to be discussed to prevent the base from weakening.

Assembly and Packing

How do the top and bottom caps stay closed?

The caps rely on friction tucks and interlocking flaps. Once folded inward 90 degrees, the flaps mesh together to lock the beveled geometry in place and provide a stable, flat footprint.

Print and Graphics

Can I print a continuous image around the entire column?

Yes, the eight-panel tube allows for wraparound graphics. However, you should plan the artwork carefully around the creases at the beveled edges so that logos or text do not break across a fold.
