FEFCO 0210

Straight Tuck Carton

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Unbroken front and back panels for premium retail display
Fast manual packing for lightweight goods
Requires fine flutes or cartonboard to prevent tabs from binding

About this product

The straight tuck carton is a die-cut box that closes with friction tabs on both ends. Because both the top and bottom lids hinge from the same rear panel, the front face remains completely smooth and unbroken by cut edges. This creates a clean canvas for retail branding and a simple unboxing experience.

While the friction closure allows for fast hand assembly, it also dictates the material and shipping route. The tuck tabs rely on precise clearances to stay shut, making this style an excellent match for thinner corrugated flutes or cartonboard, but a poor choice for heavy double-wall board or standalone parcel shipping.

Common uses

Retail cosmetics and consumer goods
E-commerce inner cartons inside a master shipper
Software, electronics, and kitted parts
Pharmaceutical and specialty food packaging

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Length (inside)

Width (inside)

Height (inside)

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How heavy is the item going inside?

How will this box be shipped to the final customer?

Will you use a custom insert to hold the product in place?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail, display, and inner-carton packing

Primary retail and shelf-ready packaging

The straight tuck carton keeps the focus on the product. With clear display faces free of meeting-flap seams, it presents high-quality graphics cleanly on store shelves.

E-commerce inner cartons

When placed inside a master shipping box, the straight tuck carton provides a premium unboxing moment. The end-user can open and re-close the box easily without destroying the packaging.

Kitting and lightweight parts

For internal kitting or sales demo sets, the friction closure allows operators to load, check, and reseal the contents quickly.

Pharmaceutical and cosmetic secondary packaging

The smooth front panel accommodates detailed regulatory text and branding, while the tuck ends allow quick access to small bottles or jars.

Consumer goods, cosmetics, and electronics

Cosmetics and consumer goods

Brands relying on visual impact benefit from the continuous front panel. The rear-hinging lids ensure that the raw edge of the corrugated board faces the back of the package, not the consumer.

Software and electronics

Products that require a precise feel during unboxing fit well here. The friction tab provides a satisfying, repeatable closure that implies quality.

Specialty food and confectionery

For lightweight treats, the clean lines and easy-opening lids create a high-end presentation that elevates the perceived value of the contents.

When to compare reverse tucks or slotted boxes

Reverse tuck cartons for board efficiency

If you are running a very high-volume order and want to maximize material yield, a reverse tuck carton (FEFCO 0211) nests slightly better on the cutting die, though it places one lid hinge on the front face.

Slit-lock tucks for heavier contents

If your product is dense enough to push the bottom flaps open, compare a slit-lock carton (FEFCO 0212). The small locks bite into the dust flaps for extra security, though they take a moment longer to assemble.

Slotted boxes for heavy transit

If the box will travel individually through a courier network or carry heavy industrial parts, a standard slotted box (FEFCO 0201) with taped meeting flaps provides much higher base strength.

Close variants and lookalike dielines

The closest library neighbors include 0211, 0212a, 0215a. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board thickness, flute profile, and closure security

Matching flute profile to friction needs

Friction tucks demand tight tolerances. Fine flutes like E or F fold crisply and slide into the tuck slot smoothly. Thicker B or C flutes can work but require careful adjustment of the fold allowances. Heavy double-wall board will almost always crush or bind during assembly.

Parcel sealing and outer carton choice

Friction tabs are designed for easy access, which means they may open if dropped. If this box will ship directly to a consumer via parcel delivery, plan to add a clear wafer seal or place it inside a protective outer mailer.

Print layout and display face orientation

Because both lids hinge from the back, the front panel is entirely uninterrupted. This allows for continuous artwork across the primary display face.

Packing line assembly speed

Evaluate your hand-packing volume. The pre-glued side seam means operators only need to square the tube and tuck the ends, making it much faster than erecting and taping a slotted box.

Tuck friction and dust flap clearances

Tuck tab shoulder and radius tuning

The depth of the tuck tab and the roundness of its corners can be adjusted based on the board thickness. A tighter clearance holds the lid more securely, while a looser clearance speeds up hand packing.

Dust flap angles

The inner dust flaps feature angled relief cuts to prevent them from catching on the lid as it closes. These angles can be modified if your specific product requires more internal shelf support.

Slit locks for added base security

If the product weight tests the limits of a standard friction tuck, small locking slits can be added to the tuck tab to bite into the dust flaps, creating a firmer hold.

Board and packing details

Die-board nesting and blank sprawl

Because both lids extend from the same vertical plane, straight tuck blanks have a slightly wider footprint than reverse tucks. This can affect how many boxes fit on a single corrugated sheet during production.

Flat delivery and hand assembly

The factory glues the side seam and delivers the boxes as flat tubes. The operator simply squeezes the edges to square the box, folds in the dust flaps, and pushes the tuck lids closed.

Factory layout adjustments

Alternative factory layout (0210a)

Shifts the glue flap position to optimize the flat blank for specific folder-gluer machinery, with no change to the final assembled box.

Additional notes

Print panel and scuff risk

The unbroken front panel is excellent for high-end graphics. However, consider how the boxes will be packed into master shippers; tight packing without dividers can cause the printed faces to rub against each other during transit.

Insert clearance for small parts

If your product shifts during transit, it can push against the dust flaps and loosen the tuck tab. A well-fitted insert prevents the product from resting its weight directly on the closure.

FAQs

Visuals and presentation

What is the difference between a straight tuck and a reverse tuck?

On a straight tuck carton, both the top and bottom lids hinge from the same panel (usually the back). This leaves the front face completely smooth. On a reverse tuck, the top lid hinges from the back and the bottom lid hinges from the front, which saves a small amount of material during manufacturing but puts a cut edge on the primary display face.

Route and shipping

Can I ship a straight tuck carton through the mail as a standalone parcel?

Parcel networks involve drops and impacts that test friction closures. While the tuck tab holds well on a shelf, an individual courier shipment often benefits from a clear wafer seal, a security label, or an outer shipping box to prevent the lid from opening in transit.

Board and material

Can this box be made in heavy double-wall corrugated board?

Using thick double-wall board for a friction tuck is generally a poor match. The thick material causes the tuck tabs to bind against the front panel, making the box frustrating to assemble and often crushing the corrugated edges. Fine flutes or cartonboard provide the crisp folds this box requires.

Production path

Does this style require die-cutting?

Yes. The rounded corners on the tuck tabs and the angled cuts on the dust flaps cannot be produced on simple straight-knife slotting equipment. The box is run on a flatbed or rotary die-cutter to achieve the precise clearances needed for the friction fit.

Packing labor

Is this box fast to pack by hand?

Yes. Because the side seam is already glued by the factory, the operator only needs to pop the tube open and fold the ends. It eliminates the need to handle tape dispensers or fold complex locking bases, making it fast for manual packing lines.

Inserts and product fit

Can I use internal dividers or inserts with this box?

Yes, but the insert must be sized carefully. It needs to sit slightly below the fold line of the dust flaps so it does not block the tuck tab from sliding fully into the front panel gap.

Samples and prototyping

Should I test the friction fit before ordering?

Yes. Because the tuck tabs rely on precise clearances, testing a physical sample with your exact board choice ensures the lids slide in smoothly without binding or tearing.

Storage and delivery

How do these boxes arrive?

The factory glues the side seam and ships them flat. You simply squeeze the edges to square the box before loading your product.
