FEFCO 0716

Shelf-Ready Two-Cell Display Box

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Base locks automatically when squared to remove the need for bottom tape
  • Integrated flaps fold down to create two separated internal cells
  • Attached lid opens upright to form the display header

About this product

This single-piece corrugated box combines a crash-lock base with an integrated two-cell divider. It keeps paired items separated while the hinged lid opens upright as a display header.

Building the partition into the main blank avoids a separate divider. At the store, staff open the attached lid and stand it upright rather than tearing it away.

Common uses

  • Twin-pack retail promotions
  • Fragile glass bottles or jars
  • Checkout zone impulse displays
  • Specialty food and beverage kits

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Product types and retail display jobs

Twin-pack retail promotions

The built-in divider keeps two distinct products separated during transit. When the top is torn away, both items sit side-by-side in a branded tray. This fits paired specialty foods, cosmetic sets, or promotional bundles.

Fragile bottles and jars

For glass goods that require physical separation, the integrated partition provides a buffer. This removes the need to source, store, and manually load separate cardboard inserts on the packing line.

Checkout zone impulse displays

The compact two-cell footprint works well for small, neatly packaged items placed near retail registers. The tear-away top allows fast shelf stocking without box cutters.

Specialty food and beverage kits

Pairs of sauces, syrups, or craft beverages fit naturally into the divided cavity. The crash-lock base supports the weight during pallet transit, while the open tray presents the labels clearly to shoppers.

Supply chain and packing environments

High-volume retail distribution

This box requires a multi-point folder-gluer to manufacture. It makes the most sense for medium-to-high volume repeat programs where the pack-bench speed of a crash-lock base offsets the initial tooling requirements.

FMCG and grocery supply chains

Grocery environments prioritize fast shelf replenishment. The tool-free tear-away top allows store staff to move products from the pallet to the shelf in seconds, leaving a clean, branded tray.

Co-packing and fulfillment centers

Packing teams gain the speed of an auto-erecting base and a built-in divider. Operators square the box, fold down the partition flaps, and load the product without handling separate partition pieces.

When to compare other shippers or displays

Standalone parcel and e-commerce shipping

The friction-tuck lid and tear-away perforation are designed for palletized retail distribution. If you are shipping individual orders through a courier network, the perforation acts as a weak point. A standard crash-lock box (FEFCO 0700) without the tear-away feature is a safer choice for direct-to-consumer fulfillment.

Multi-item beverage packing

If you are packing six or more items, such as craft beer or wine bottles, a multi-cell integrated divider (FEFCO 0715) provides the necessary grid structure while maintaining the crash-lock assembly speed.

Close variants and lookalike dielines

The closest library neighbors include 0728, EVC11050, 0886. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board, print, and route decisions

Board thickness and tear performance

This package relies on precise clearances. If the corrugated board is too thick, the internal partition will bind during assembly, and the perforation will be too tough to tear cleanly by hand. Fine to medium flutes generally provide the best balance of print quality, easy folding, and a clean retail tear.

Production volume and routing

Because this box requires a flatbed die-cutter for the perforations and a multi-point folder-gluer for the crash-lock base, it is built for scale. It fits repeat retail programs rather than short-run trials.

Closure security for the shipping route

The top seals with a friction tuck-in flap. While this is sufficient for stretch-wrapped pallets, mixed-transit routes may require a clear wafer seal or tape over the tuck flap to prevent it from popping open.

Print placement for the display transition

Because the top half of the box is discarded at the retail store, critical branding and product information must sit on the lower tray section. The inside of the back wall can also be printed to serve as a branded backdrop once the lid is removed.

Lid, flap, and tear-line modifications

Magazine slots and thumb notches

The top tuck-in lid can be modified with a thumb notch or magazine-style slot. This makes the box easier to open for inspection before the final retail display tear, though it slightly reduces the seal against dust.

Dust flap locking shoulders

The inner dust flaps can be cut with locking shoulders to increase the friction of the top tuck closure, helping the lid stay secure during pallet movement.

Perforation pitch tuning

The cut-to-tie ratio of the tear line must be adjusted based on the exact board grade chosen. A tie that is too strong makes the box impossible to open in the store, while a tie that is too weak risks the box breaking apart during transit.

Board and packing details

Internal partition clearance

The cell width is strictly tied to the material thickness. Changing the board grade requires recalculating the partition fold allowances to prevent the flaps from binding when the operator pushes them down.

Design adjustments

Alternate top flap profiles

The tuck flap can be cut with a straight edge or a slotted profile depending on the required friction fit and the specific stripping limits of the flatbed die-cutter.

Additional notes

Print panel and retail visibility

When designing artwork, remember that the top half of the box will be torn off and fiber-based. Keep primary logos, barcodes, and essential product details on the lower half of the walls so they remain visible on the retail shelf.

Related retail and crash-lock packaging

EVC11050: Box Display - Snap Lock

EngView neighbor that can look close in CAD. Review it if a sample or dieline seems similar, then verify closure style, slots, wall build, and assembly before treating it as a substitute.

FAQs

Shipping and Route

Can this box be shipped directly through the mail?

It is not recommended for standalone parcel shipping. The friction-tuck lid can pop open, and the tear-away perforation weakens the vertical strength under rough handling. It performs best when stacked on pallets for retail distribution.

Inserts and Fit

Do I need to order separate dividers for this box?

No. The two-cell partition is cut from the same piece of corrugated board as the outer walls. When the box is squared open, the partition flaps fold down into the center, creating the divider automatically.

Board and Finish

Can this be made in heavy-duty double-wall board?

Usually not. Heavy boards make the internal partition difficult to fold and cause the crash-lock base to bind. More importantly, thick board makes the retail perforation almost impossible to tear cleanly by hand. We recommend fine or medium flutes.

Quantity and Production

Why is this style better suited for large orders?

The complex base and integrated partition require a multi-point folder-gluer to manufacture. The setup process for this machinery makes short runs difficult to justify financially. It is designed for scale and repeat programs.

Samples and Prototypes

Will a digital prototype test the tear-away feature?

A digitally cut sample will prove the size, fit, and partition clearance. However, digital cutting tables cannot perfectly replicate the exact tear resistance of a factory steel perforation rule. The final tear feel must be validated during the production run.

Assembly and Labor

How does the internal divider stay in place?

The divider relies on precise fold clearances. After the operator squares the box to deploy the crash-lock floor, they push the top partition flaps downward. The flaps wedge against the bottom and side walls, holding their position through friction.

Retail Display

Can the top lid be resealed after it is torn open?

No. The horizontal perforation is a destructive tear designed for one-way conversion. Once the retailer pulls the strip to remove the top half of the box, it remains an open display tray permanently.

Assembly and Labor

Does the crash-lock base require tape?

The base interlocks automatically when the box is squared, creating a rigid floor without bottom tape. However, the top tuck-in lid may require a clear seal depending on your shipping route.
