FEFCO 0833

Multi-Shelf Retail Display Stand with Double Side Walls

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Multi-piece unglued kit with a main body frame and separate drop-in shelves
  • Side walls fold 180 degrees to form double-thick structural support columns
  • Ships knocked-down flat for dense transit to co-packers or retail stores

About this product

This multi-piece corrugated display stand creates a freestanding retail fixture with a tall backboard and multiple open-front shelves. It ships flat as a kit and relies on side walls that fold 180 degrees back on themselves to create double-thick structural columns.

Because the entire unit locks together through mechanical friction and tuck tongues, it requires no tape or glue. The main tradeoff is the manual assembly effort. Retail staff or co-packers must pre-break the long side creases and carefully insert each shelf, making board thickness a careful balance between payload strength and folding difficulty.

Common uses

  • End-cap promotions
  • Countertop impulse bins
  • Trade show literature racks
  • Seasonal retail pushes

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail floor and promotional display setups

End-cap and aisle product launches

The tall rear panel provides a large billboard space, drawing attention in busy retail aisles. The open shelves work well for boxed goods, lightweight cosmetics, or packaged snacks where shoppers need quick, unobstructed access.

Trade show and event literature racks

When scaled appropriately, the flat shelves easily hold brochures, sample kits, or promotional giveaways. The entire unit packs flat for transport to the event and can be assembled on-site without tools.

Countertop point-of-sale presentations

Scaled down and cut from thinner board, this exact display organizes small impulse items like lip balm, gift cards, or travel-sized toiletries right at the register.

Seasonal and temporary retail promotions

Because the unit ships flat and requires no permanent hardware, it works well for short-term holiday pushes or limited-edition product runs where a permanent metal or wood fixture is unnecessary.

Channels relying on freestanding merchandising

Consumer goods brands

Brands use these stands to secure off-shelf placement in grocery and pharmacy environments, relying on the tall back panel for high-visibility marketing.

Co-packing and fulfillment centers

Facilities that pre-load displays before shipping to retail need to account for the assembly time. The 180-degree side folds and individual shelf insertions add labor minutes before the actual product packing begins.

Event marketers and trade show exhibitors

Teams traveling to events rely on the knocked-down flat delivery. The entire unit can be transported easily and assembled on-site without tools, then broken down or fiber-based after the show.

Comparing other corrugated display stands

Hollow rolled columns versus flat double walls

If you need thicker, more rigid vertical supports, compare this to a display with hollow rolled pillars (like 0831). The 0833 uses flat, double-layered walls, which can be slightly faster to fold but may offer different lateral stability depending on the board grade.

Tiered or cascading product visibility

If products on the lower shelves are hard to see, consider a sloped display (like 0832). It angles the side walls backward, creating a tiered presentation that improves sightlines for the bottom rows.

Close variants and lookalike dielines

The closest library neighbors include 0830, 0831, 0840. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board thickness, assembly labor, and production routing

Balancing board thickness and operator fatigue

The side walls must fold completely flat against themselves. If the corrugated board is too thick, these 180-degree folds will bind, fighting the operator and making shelf insertion difficult. Fine or medium flutes usually perform better than heavy double-wall board.

Large-scale die-cutting limits

For a full-height floor display, the main backboard and side-wall blank is massive. This requires large-scale flatbed die-cutting equipment, which can influence which converters can run the job and how much offcut waste is generated.

Pre-breaking the main creases

To ensure the shelves slide in smoothly, whoever assembles the display must pre-break the long vertical creases on the side walls. Skipping this step leaves tension in the board, which can cause the side walls to bow outward and the shelves to drop.

Print surface and graphic alignment

The tall rear panel and double-thick side walls offer a large canvas for branding. You must decide whether to print on both sides of the board, as the inner faces of the side walls are visible to shoppers once folded.

Adjusting shelf count and clearance

Shelf count and vertical spacing

The number of shelves and the distance between them can be adjusted to match the product height. Adding more shelves increases the number of separate pieces in the kit and the total assembly time.

Tuck tongue and slot tolerances

The shelves lock into the side walls using side tabs. The slots receiving these tabs must be sized exactly to the chosen board thickness to prevent the shelves from tearing out under weight or being too tight to insert.

Header card extensions

The top of the backboard can be extended or die-cut into custom shapes to serve as an integrated header, drawing more attention in crowded retail aisles.

Board and packing details

Testing shelf weight capacity

Because the shelves are supported only by their side tabs and the friction of the side walls, they are vulnerable to center sag. Always test a physical prototype with the actual product weight before committing to a full production run.

Additional notes

Shelf front lip reinforcement

Each shelf features a front lip that folds down 90 degrees. This creates a structural beam to resist bowing under the weight of the product.

Related retail displays

0830: Related template 0830

Nearby FEFCO style to review if the buyer wants a similar job but the closure, flap overlap, wall build, or part count changes the package choice.

0840: Related template 0840

Nearby FEFCO style to review if the buyer wants a similar job but the closure, flap overlap, wall build, or part count changes the package choice.

FAQs

Assembly and Packing

Does this display require glue or tape to assemble?

No. The entire unit locks together using mechanical friction. The side walls fold over to create double-thick columns, and the shelves slide into pre-cut slots to hold the frame rigid.

Can this be assembled by automated equipment?

No. This is a multi-piece architectural fixture that requires two-hand manual assembly, either at a co-packing facility or by retail staff on the store floor.

Shipping and Route

Can I ship the fully assembled display through a parcel courier?

No. Because it is an open-front retail fixture held together by friction locks, shipping it fully assembled through mixed-carrier networks risks the shelves dislodging. It should ship knocked-down flat in a master shipper, or be palletized and stretch-wrapped if shipped pre-loaded with product.

Board and Material

Should I use heavy double-wall board for maximum strength?

Often not. While heavy board increases payload capacity, it makes the 180-degree side wall folds extremely stiff. This can cause the folds to bind, making manual assembly exhausting and risking crushed locking tabs.

Product Fit

How much weight can each shelf hold?

Weight capacity depends entirely on the board grade, shelf width, and the size of the locking tabs. Because the shelves lack center support, they must be physically tested with your specific product to check for sagging.

Production

Why does this display require large-scale tooling?

The main body, comprising the tall backboard and the wide fold-over side walls, is cut from a single piece of corrugated board. For a floor-standing unit, this blank is often too large for conventional die-cutting presses.

Print and Graphics

Can I print on the inside of the side walls?

Yes. Because the side walls fold 180 degrees back on themselves, the inside of the display column is actually the reverse side of the main corrugated blank. Discuss two-sided printing with your converter if you want graphics on the inner walls.

Product Fit

How are the shelves kept from sagging in the middle?

The shelves rely on front folded lips that act as structural beams. For heavier products, the board grade of the shelf itself may need to be upgraded, or a center support pillar can be added to the design.
