FEFCO 0852

Slanted Retail Dump Bin

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Pops open from a flat-shipping glued tube for fast store-level setup
  • Slanted side profile maximizes product visibility and access
  • Manual interlocking base supports lightweight to medium bulk goods

About this product

A one-piece corrugated display stand designed to present loose or bulk merchandise at an inclined angle. The tall back panel provides a large billboard for branding, while the slanted side walls and low front lip keep products visible and accessible to shoppers.

Because the side seam is factory-glued, the display ships flat and pops open into a rigid tube at the store. Retail staff simply fold and interlock the bottom flaps to secure the floor before loading the product.

Common uses

  • Countertop impulse buys
  • Floor-standing bulk promotions
  • Lightweight packaged snacks
  • Endcap merchandising

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Merchandising and Floor Presentations

Floor-standing bulk promotions

Scaled up with heavier board, the tall back wall provides vertical column strength while acting as a primary branding surface. The open bin holds loose items like packaged snacks, seasonal goods, or lightweight apparel.

Countertop impulse displays

Produced in finer flutes, the slanted profile fits neatly near registers. The low front lip keeps small items like lip balm, travel toiletries, or hardware accessories contained while keeping them fully visible.

Endcap merchandising

Placed at aisle ends, the angled presentation catches shopper attention from multiple directions. The single-piece construction makes it easy to swap out for seasonal campaigns.

Lightweight apparel bins

Used for rolled t-shirts, socks, or accessories, the deep base allows customers to dig through inventory without collapsing the side walls.

Fulfillment and Store-Level Operations

Retail rollouts and co-packing

Because the side seam is glued at the factory, the display arrives as a flat tube rather than a complex kit of loose parts. This reduces the time retail staff or co-packers spend squaring up the frame, leaving only the base flaps to fold and lock.

Fast-moving consumer goods

Brands needing quick deployment across hundreds of stores benefit from the pop-open design. The single-piece format eliminates the risk of missing parts during store-level assembly.

Trade shows and pop-up shops

The ability to ship the unit completely flat and erect it without tools makes it highly portable for temporary retail environments.

When to Consider a Different Display Style

Gravity-fed dispensing

If your product needs to feed out from the bottom rather than being picked from an open top, a bottom-dispensing stand controls the flow of individual boxes or bottles much better than an open dump bin.

Massive floor footprints

For very large floor displays, a single-piece blank can become too large for standard flatbed presses. In those cases, a multi-piece unglued display may be more practical to manufacture, though it shifts more assembly labor to the store.

Heavy payload stacking

The open slanted top offers zero vertical crush protection. If you need to stack loaded displays on top of each other during transit, you need a structural tray or a master shipper.

Instant base assembly

While this tube pops open quickly, the floor still requires manual folding. If you need the absolute fastest setup, a crash-lock base eliminates the manual floor-folding step entirely.

Close variants and lookalike dielines

The closest library neighbors include 0861, 0841, 0403. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board, Fit, and Assembly Choices

Board thickness versus folding effort

Heavy board gives the tall back panel excellent vertical rigidity for floor displays. However, thicker board makes the bottom interlocking flaps harder to fold by hand. The board choice must balance overall stability with the physical effort required from retail staff.

Front lip height and product retention

The height of the front panel determines how much product the bin can hold before spilling. A lip that is too low allows bulk items to fall out, while a lip that is too high hides the merchandise.

Center of gravity and tipping risk

Because the side walls are slanted, the weight of the product pushes forward against the front lip. The angle of the incline must be balanced against the depth of the base to ensure the display remains stable.

Master shipper sizing

Because this display has an open top, it cannot ship through a parcel network on its own. You must plan for a separate corrugated master shipper to transport the loaded or flat display to the store.

Practical Template Adjustments

Side wall inclination

The angle of the slanted side walls can be adjusted. A steeper angle creates a deeper bin with more internal capacity, but shifts the center of gravity forward, which must be tested to ensure the display does not tip.

Back panel contouring

The tall back billboard does not have to remain a simple rectangle. The top edge can be die-cut into custom shapes to match brand logos or product silhouettes.

Base lock style

The exact cut of the interlocking bottom flaps can be modified based on the product weight and chosen board thickness, ensuring the floor does not tear under pressure.

Board and packing details

Flatbed die-cutting requirements

The slanted side cuts and interlocking base slots require flatbed die-cutting. This format cannot be produced on a standard rotary slotter.

Base and Profile Options

Base lock styles

While the template relies on interlocking bottom flaps, the exact cut of those flaps can be adjusted based on the product weight and the chosen board thickness.

Additional notes

Center of gravity and tipping risk

Because the side walls are slanted, the weight of the product pushes forward against the front lip. The angle of the incline must be balanced against the depth of the base to ensure the display remains stable on the retail floor.

Related Display Structures

0801: Crash-Lock Display Tray

Review this alternative if you want the absolute fastest store-level setup. It uses a factory-glued auto-bottom instead of manual flaps, but features straight side walls rather than a slanted profile.

0834: Multi-Piece Slanted Display

Review this alternative for very large floor displays. It uses a similar slanted profile but relies on unglued tab-and-slot assembly, which lowers factory costs but increases store-level labor.

0825: Bottom-Dispensing Stand

Review this alternative when products should feed out from a bottom chute rather than being picked from an open top bin.

0861: Related template 0861

Nearby FEFCO style to review if the buyer wants a similar job but the closure, flap overlap, wall build, or part count changes the package choice.

0841: Related template 0841

Nearby FEFCO style to review if the buyer wants a similar job but the closure, flap overlap, wall build, or part count changes the package choice.

FAQs

Shipping and Route

Can this display be shipped directly through a parcel network?

Because the top is completely open and the slanted sides offer no vertical crush protection, the loaded display requires a separate master shipping box for transit.

Assembly and Labor

Does this display set up automatically?

The main body pops open instantly because the side seam is glued at the factory. However, the floor of the bin requires a person to manually fold and interlock the bottom flaps.

Product Fit

How much weight can the base hold?

The weight capacity depends entirely on the board grade and the specific style of the interlocking base flaps. Heavy bulk goods require a physical mockup to ensure the bottom tabs do not tear or burst under pressure.

Print and Finish

Where is the best place for branding?

The tall back panel acts as the primary billboard, as it extends above the product line. The slanted side walls and the front lip also offer continuous, highly visible surfaces for retail graphics.

Samples and Prototypes

Why is a physical sample important for this display?

A sample proves three critical things: that the front lip is high enough to keep your product from spilling, that the base locks securely under the actual product weight, and that the display will not tip forward when fully loaded.

Production Path

Why does board thickness matter for assembly?

While thicker board makes the back wall stronger, it also makes the bottom locking tabs much stiffer. If the board is too heavy, retail staff may struggle to fold the base, or the tabs may bind and tear during setup.

Product Fit

Can I change the angle of the slanted sides?

The incline angle can be adjusted to hold more volume, but making it too steep shifts the center of gravity forward. You must test the loaded display to ensure it does not tip over on the retail floor.

Assembly and Labor

Do I need tape or glue to set this up in the store?

No additional adhesive is required at the point of use. The side seam arrives already glued, and the bottom flaps lock together mechanically to form the floor.
