ICB10041

Rigid Board Multiple-Shelf Floor Display

The ICB10041 is a freestanding, heavy-duty retail merchandiser designed for thick rigid boards like honeycomb or inverted corrugated board (ICB). Instead of using separate drop-in shelves, the shelves are cut directly into the central back panel, folding forward to lock into the side walls.

Because it relies on friction-fit tabs and rear stabilizing struts rather than glue, the entire unit ships flat and is assembled manually on the retail floor. The thick board construction provides a strong vertical presence and stability for heavier product assortments.

Get a quote
  • Order custom samples, short runs, or production runs.
  • US-based. Nationwide service.
  • Nationally competitive pricing & delivery costs.
  • Available in a wide variety of configurations.

At a glance

  • Integrated fold-down shelves with protruding side-tab locks
  • Four separate rear cross-struts prevent side-wall splaying
  • Ships flat for manual in-store assembly without adhesive

Get a quote

Share what you know. Exact specifications can follow. Or email us at info@herculeindustrial.com

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for display board preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Merchandising and Floor Placement

Freestanding Retail Floor Displays

This display is built to stand independently in retail aisles or endcaps. The thick rigid board and rear cross-struts provide the stability needed for a tall, multi-shelf presentation without requiring a permanent metal or wood fixture.

Short-to-Medium Run Promotions

Because it is typically cut on digital flatbed routers, this display fits seasonal promotions, regional product launches, or targeted retail campaigns where a custom rigid presentation is needed quickly.

Heavy Product Merchandising

The 16mm rigid board construction and interlocking rear struts offer vertical support, making this display a practical choice for heavier retail items that might cause standard corrugated shelves to sag.

Flat-Packed Retail Distribution

The entire unit, including the main body and separate rear struts, ships flat. This makes it easier to distribute to individual retail locations compared to pre-assembled permanent fixtures.

Promotional Campaigns and In-Store Assembly

In-Store Assembly Teams

Retail staff must assemble the display on-site. The design uses a slot-and-tab system. The side walls fold forward, the shelves drop down, and the rear struts push into place. While it requires no glue or tape, the process involves aligning multiple thick-board tabs, which should be tested with a physical sample to ensure store teams can handle the setup smoothly.

Brand Marketing Campaigns

The large side walls and central back panel provide uninterrupted surfaces for printed graphics. The raw edges of the thick board can also be incorporated into the visual design for an industrial aesthetic.

Temporary Retail Activations

For pop-up shops or temporary retail spaces, this display provides the presence of a permanent fixture while supporting recyclable-material goals when local recovery routes allow, making it easy to break down at the end of the activation.

When to Consider Corrugated or Drop-In Shelves

High-Speed Corrugated Rollouts

If you are planning a large national rollout where flatbed cutting speed and standard corrugated board are preferred, a standard corrugated display with separate drop-in shelves may be a more practical choice than routing 16mm rigid board.

Heavy-Duty Pallet Displays

If the product assortment is exceptionally heavy or requires forklift handling directly onto the retail floor, a reinforced pallet display or a corrugated bin with a central load-bearing spine should be evaluated instead of a freestanding shelf unit.

Material Thickness and Blank Size Considerations

Board Thickness and Slot Width

The default design assumes a 16mm rigid board. If you choose a thinner 10mm board or a different material, the CAD file must be parametrically updated so the locking slots match the new caliper. Mismatched slots will result in a loose, unstable display.

Kitting the Rear Struts

The display consists of one large main body and several separate rear cross-struts. You will need to decide how these components are kitted together for flat shipping to ensure all pieces arrive at the retail location in a single package.

Shelf Count and Vertical Clearance

The number of shelves and the distance between them must be finalized based on the exact height of the products being merchandised. The template can adjust these parameters before cutting.

Print Coverage and Exposed Edges

Because the shelves fold down from the back panel, the front edge of each shelf exposes the raw core of the board. You must decide whether to leave this edge raw or apply edge banding, and determine which sides of the flat blank require printing.

Adjusting Shelf Count and Display Slant

Shelf Count and Spacing

The template can be adjusted to increase or decrease the number of shelves, as well as the vertical clearance between them, to accommodate different product heights.

Side Wall Slant

The backward slant of the side walls can be modified. A steeper slant changes the visual profile and shifts the center of gravity, which should be reviewed to ensure the display remains stable when fully loaded.

Header Profile

The top profile of the side walls and the back panel can be shaped to match specific brand artwork or promotional themes, provided the stability of the top shelf is maintained.

Packing details

Print Surfaces and Exposed Edges

Because the shelves fold down from the back panel, the front edge of each shelf exposes the raw core of the board. Depending on the material used, this edge can be left raw for an industrial look or treated with edge banding. The primary print areas are the outside of the side walls and the inside of the central back panel.

Shelf Dimensions and Load Limits

Shelf Depth and Width

Shelf dimensions can be expanded, but deeper shelves increase the leverage on the side tabs and may require physical testing to verify they will not sag under heavy product weight.

Additional notes

Slot width dependencies

Every locking slot in this design is tied to the exact thickness of the board. Changing from a 16mm to a 10mm board requires a full parametric update before cutting.

Related Floor Displays

FAQs

Does this display require glue or tape to assemble?

No. The display relies entirely on friction and interlocking tabs. The shelves lock into the side walls, and separate rear struts lock the side walls at a 90-degree angle.

Can this be made from standard corrugated board?

It is designed for thick rigid boards like 16mm honeycomb or inverted corrugated board. While it can theoretically be adapted for thinner corrugated board, the tall, freestanding nature of the design usually requires the stiffness of a premium rigid material to prevent bowing.

How is the display shipped to stores?

It ships flat. Because the main body is a single large piece of thick board, it typically requires a custom outer shipper or palletized delivery, rather than standard parcel shipping.

How much weight can each shelf hold?

Weight capacity depends entirely on the specific board grade chosen and the width of the shelf span. Because the shelves are supported by side tabs rather than a folded front lip, heavy items should be tested with a physical prototype to check for sagging.

Where does the artwork go on this display?

The most visible areas are the exterior side walls, the header area, and the interior back panel behind the products. Keep in mind that folding the shelves down leaves rectangular cutouts in the back panel, which will be visible if the shelves are not fully stocked.

Why is a physical sample necessary?

A prototype confirms that the slot widths perfectly match your chosen board thickness, ensuring the friction locks hold tightly. It also allows you to test the assembly process and verify the display will not tip forward when loaded.

Are the rear supports attached to the main display?

No. The rear cross-struts are separate pieces of rigid board. They must be packed and shipped together with the main body blank so the store has all the necessary parts for assembly.

Can store staff adjust the shelf heights after assembly?

No. The shelves are cut directly into the central back panel at fixed intervals. The shelf spacing must be determined and locked into the design before the board is routed.

A tall, rigid-board merchandiser that uses its own geometry to lock together on the retail floor.
