EVP11019

Clear Plastic Hanging Box with Greenleaf Bottom

The EVP11019 is a clear plastic folding carton built for retail pegboard displays. It combines 360-degree product visibility with an integrated euro-hanger that threads through a slotted top flap, keeping the package closed without extra stickers.

Delivered flat with a glued side seam, this box features a decorative 'Greenleaf' interlocking bottom. Because the four bottom flaps curve and lock together manually, it avoids the visual clutter of glued or taped base flaps, making it a practical fit for lightweight cosmetics, electronics, or retail accessories.

Get a quote
  • Order custom samples, short runs, or production runs.
  • US-based. Nationwide service.
  • Nationally competitive pricing & delivery costs.
  • Available in a wide variety of configurations.

At a glance

  • Integrated hanger tab keeps the top closed
  • Glue-free interlocking Greenleaf bottom
  • Built for hand-packing operations

Get a quote

Share what you know. Exact specifications can follow. Or email us at info@herculeindustrial.com

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for clear plastic preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Display and Pegboard Presentation

Lightweight Pegboard Retail

The integrated hanger and clear walls make this package useful for retail environments where the product needs to sell itself visually. The hanger tab is cut directly from the top flap, helping it stay aligned on the peg.

Cosmetics and Beauty Products

Often used for items like makeup brushes, small bottles, or skincare accessories. The Greenleaf bottom provides a clean, decorative look that keeps the focus on the product rather than the packaging mechanics.

Tech Accessories and Cables

A practical choice for charging cables, adapters, or lightweight electronics. The clear plastic allows buyers to inspect the connectors and cable length without opening the package.

Small Toys and Collectibles

Useful for displaying small figures or blind-box items where 360-degree visibility adds to the retail appeal. The interlocking bottom carries lightweight items without distracting tape.

Product Categories and Fulfillment Fit

Manual Packing Operations

This carton is built for hand-packing operations. Packers fold and interlock the curved bottom flaps, load the product, and thread the top hanger tab through its receiving slot. The threading and interlocking motions make it difficult to run on automated cartoning lines.

High-Visibility Retail Environments

When the product design or color is the primary selling point, clear plastic removes the barrier between the item and the buyer. This is especially useful in crowded retail aisles where printed paperboard might blend in.

Mixed Shelf and Pegboard Displays

While built for hanging, the flat Greenleaf bottom allows the box to stand upright on a shelf if needed. This gives retailers flexibility in how they merchandise the product across different store layouts.

When to Consider Different Bottom Closures or Tops

Heavy Products or Automated Assembly

If the product is heavy, the interlocking Greenleaf bottom may bow and release. In those cases, a snap-lock (1-2-3) bottom or a glued auto-bottom is worth comparing. If packing speed is critical, a common tuck bottom may be faster to assemble by hand.

Shelf-Only Display

If pegboard hanging is unnecessary, a common flat-top box will stack much easier on shelves and avoids the protruding hanger tab.

Material, Scoring, and Transit Choices

Plastic Type and Creasing

Clear PVC and PET behave differently when folded. To reduce the risk of the plastic cracking or turning white at the hinges, the material often uses specialized heated creasing during die-cutting. The exact plastic grade depends on clarity and environmental goals.

Master Shipper Use

Clear plastic is prone to scuffing during transit. These boxes ship knocked-down flat, but the final packed product usually needs a well-fitted corrugated master carton to reduce courier damage to the plastic surfaces and hanger tabs.

Print and Finish Options

While often left completely clear, the plastic can be printed with branding or instructions. If printing is planned, consider how the boxes will rub against each other during transit, as protective films or varnishes may be useful.

Hanger Hole Style

The template defaults to a common euro-hole, but the punch shape can be modified to fit different retail peg fixtures, such as a simple round hole or a delta punch.

Hanger Hole and Dimension Adjustments

Hanger Hole Specifications

The euro-hole dimensions can be adjusted to match specific retail pegboard standards. The vertical offset and width of the slot can also be tuned to help the tab stay in place.

Box Dimensions and Proportions

Length, width, or height can be scaled to fit the product. However, the Greenleaf bottom relies on specific geometric ratios, so unusual aspect ratios may change how the bottom flaps interlock.

Plastic Thickness

The default thickness is 0.5mm, which balances folding behavior with hanging stability. Thicker plastic increases strength but can make the manual interlocking process more difficult.

Packing details

Top Closure Locking Mechanism

The top of the box does not rely on simple friction tucks. Instead, the hanger tab folds up and passes through a precise slot in the inner top flap. This action simultaneously exposes the hanger and keeps the top of the box closed.

Additional notes

Print surface and scuff risk

If printing graphics or text on the clear plastic, consider how the boxes will rub against each other during transit. Protective films or specific varnishes may be useful to keep the presentation clean.

Related Plastic and Hanging Boxes

FAQs

Does the bottom of this box need glue or tape?

The Greenleaf bottom uses four curved flaps that interlock manually to form a base without tape. However, the side seam of the box is glued at the factory before delivery.

Can this box be erected on automated packaging lines?

Threading the hanger tab through the top slot and interlocking the curved bottom flaps rely on manual assembly. This package is built for hand-packing operations.

Is this box suitable for heavy retail items?

The Greenleaf bottom relies on the stiffness of the plastic. Heavy items can cause the base to bow outward, potentially releasing the interlock. A physical sample should be tested with the exact product weight.

Can I ship this box directly to a customer?

This box is built for retail display, not as a shipping container. Clear plastic scratches easily, and the hanger tab can catch or tear in transit. It usually needs an outer corrugated box for shipping.

What reduces the risk of the plastic cracking at the folds?

Clear plastics like PVC and PET often use specialized heated creasing or RF scoring during manufacturing. This helps the hinges fold cleanly without whitening or snapping during assembly.

Can the hanger hole be changed to a simple round punch?

While the template defaults to a common euro-hole, the punch shape and size can be modified to fit different retail peg fixtures.

How does the top closure stay closed?

The hanger tab folds up from one of the main flaps and passes through a slot in the opposite inner flap. This threading action keeps the top closed without needing a friction tuck or clear sticker.

Do I need a physical sample before ordering?

Testing a physical sample is a practical step. It allows you to verify that the plastic thickness handles your product weight and that the manual assembly process fits your packing line.

A clean hanging display starts with matching the right plastic and closure to your product's weight.
