EVC11263

Corrugated Retail Carrying Box with Rope Handle

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Crash-lock base opens quickly for fast loading
Tapered top is secured by threading a rope or string handle
Relies on an outer shipper for parcel or courier networks

About this product

The EVC11263 is a corrugated retail carrying carton designed for premium presentation and customer convenience. It features a pre-glued crash-lock base that opens quickly for loading and a tapered roof secured by an external rope or string handle.

This box fits retail takeaway, gift sets, and promotional kits. While the auto-bottom base speeds up the initial packing step, the top closure relies on manual threading of the rope, making it a distinct choice for presentation-focused fulfillment rather than high-speed automated lines.

Common uses

Retail takeaway
Corporate gift kits
Event promotional packs
Apparel or shoe packaging

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Length

Width

Height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

Do you already have a specific rope or ribbon selected for the handle?

How heavy is the heaviest item going into this box?

How will these boxes be distributed to the final customer?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Takeaway and Promotional Kits

Retail Takeaway and Apparel

The built-in rope handle and distinctive tapered top make this box an excellent alternative to shopping bags for premium retail items, shoes, or apparel. The flat base provides stability when set down.

Corporate Gift Sets and Event Kits

For promotional events or corporate gifting, the box offers a memorable unboxing experience. The wide front and back panels provide uninterrupted space for branding and graphics.

Trade Show Handouts

The carrying handle encourages attendees to keep the box visible as they walk the floor. The auto-bottom base allows booth staff to erect the boxes quickly as needed.

Premium Food and Beverage Kits

Gourmet assortments and wine pairings benefit from the structured presentation. The flat base keeps jars or bottles upright, while the rope handle adds a high-end touch.

Presentation-Focused Fulfillment and Hand-Carry Routes

Presentation-Focused Fulfillment

This box is chosen when the final presentation matters more than absolute packing speed. The crash-lock base saves time, but fulfillment teams should account for the manual labor involved in threading and tying the rope handle.

Hand-Carry Distribution

Designed specifically for hand-carry situations, the top closure relies entirely on the rope. It is not sealed against dust or crushing, meaning it should be placed inside a master carton if it needs to travel through a courier network.

High-Volume Flat Storage

Because the box is delivered flat and the base is pre-glued, it takes up minimal space in a stockroom or under a retail counter until the moment it is needed.

When a Standard Tuck or Integrated Handle Makes More Sense

High-Speed Automated Sealing

If your packing line relies on automated top sealers or folder-gluers to close the box, the manual rope threading of this design will create a bottleneck. A crash-lock box with a tuck top is a better fit for automation.

Direct Parcel Shipping

The rope handle can catch on sorting equipment, and the tapered top is not designed to withstand heavy vertical stacking in transit. If the box ships directly to a consumer without an outer carton, a corrugated mailer is a safer choice.

Rope Sourcing, Board Choice, and Hole Stripping

Rope Sourcing and Hole Diameter

The die-cut holes should be sized to match your chosen rope or string. A tight fit slows down fulfillment, while a loose fit risks the knot pulling through. Coordinate the hole diameter with your rope supplier before finalizing the design.

Board Grade and Tear Resistance

The entire weight of the product is carried by the board surrounding the rope holes. E-flute is a common choice for its print quality and clean folding, but heavier products may need a stronger board or reinforced hole areas to prevent tearing.

Clean Hole Stripping

Ensure the manufacturing process includes clean stripping of the circular rope holes. Hanging chads or incomplete cuts will slow down the manual threading process at the packing station.

Print Surface and Finish

The wide main panels offer excellent billboard space. Selecting a board with a smooth outer liner ensures high-quality graphics for retail display.

Roof Pitch, Hole Adjustments, and Base Proportions

Roof Pitch and Taper

The height and angle of the tapered roof section can be adjusted. A steeper pitch changes the visual profile and can provide more internal clearance for taller items.

Hole Placement and Spacing

The distance between the two rope holes can be widened or narrowed to accommodate different handle lengths or carrying preferences.

Base Proportions

The length and width of the base can be scaled to fit specific product footprints, provided the dimensions remain within the limits of the folder-gluer equipment.

Packing details

Base Erection and Gluing

The crash-lock base is pre-glued by the manufacturer and delivered flat. When the packer applies pressure to the edges, the base flaps automatically interlock, creating a rigid floor.

Additional notes

Packing line labor

When planning fulfillment, account for the time required to manually thread and knot the rope handle for each box.

Flute choice and folding

E-flute is often preferred for this style because it folds cleanly at the tapered roof and provides a smooth surface for high-quality retail printing.

FAQs

Is adhesive needed to assemble this box?

The base is pre-glued by the manufacturer and locks into place automatically when opened. The top is secured entirely by threading and tying the rope handle.

Can the top closure be automated?

While the base erects quickly, threading the rope through the die-cut holes and securing it is a manual process that is done by hand.

Can I ship this box directly in the mail?

This box is designed for retail carry-out and presentation. The rope handle and unsealed top make it unsuitable for direct parcel shipping. It should be placed inside an outer shipping carton if it needs to travel through a courier network.

How much weight can the handle support?

The carrying capacity depends on the tear resistance of the corrugated board around the rope holes. For heavier items, the board grade should be tested to ensure the rope does not tear through the material.

Where is the best place for branding on this box?

The wide front and back panels offer large, uninterrupted surfaces for graphics. The tapered roof sections also provide visible branding space that faces upward when the box is carried.

Do I need to supply the rope?

The rope or string is typically sourced separately. It is important to confirm the diameter of your chosen rope so the die-cut holes in the box can be sized correctly.

Can this box be stacked on a retail display?

The tapered roof prevents stable vertical stacking. It is best displayed side-by-side or on single-level shelving.

How is the box delivered?

The carton is glued at the side seam and base by the manufacturer, then delivered flat to save storage space until it is ready to be packed.
