EVC11999

Telescoping Corrugated Tube with Plug Ends

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Adjustable length via sliding inner and outer tubes
Four-piece system requires manual assembly and sealing
Friction-fit end caps feature a finger hole for easy removal

About this product

The EVC11999 is a four-piece corrugated shipping system used for long or variable-length items. It uses two rectangular tubes that slide together to adjust to the exact length of your product, capped by two separate friction-fit end plugs.

Because the inner and outer tubes overlap, the center of the package gains double-wall strength, making it resistant to crushing. While the telescoping design reduces the need to stock multiple box sizes, the four separate components require manual folding and external sealing before shipment.

Common uses

Architectural hardware and extruded profiles
Industrial shafts and metal rods
Window blinds and long fixtures
Large rolled graphics and banners

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Width

Height

Length

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What type of items will go inside?

How will you secure the package for shipping?

How much does the length of your products vary?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Product types that fit telescoping tubes

Variable-length product lines

When a product catalog includes items of varying lengths, such as window blinds or extruded profiles, a telescoping tube allows a single packaging system to cover multiple SKUs. The outer tube simply slides over the inner tube until it meets the product.

Heavy rolled goods and industrial shafts

The overlapped section of the two tubes creates a double-wall barrier, providing crush resistance for heavy, narrow items. The separate end caps absorb axial impacts, though they often need heavy strapping to reduce the risk of heavy items pushing them out during transit.

Consolidating packaging inventory

Instead of ordering and storing ten different box lengths for a diverse product line, buyers can use one telescoping system. The sliding outer sleeve adapts to the exact length needed for each order, reducing warehouse footprint and simplifying procurement.

Replacing round mailing tubes

Round tubes are prone to rolling off sorting conveyors and warehouse shelves. This rectangular profile stays flat, making it easier to stack and palletize while offering similar length flexibility for posters and rolled graphics.

Industries shipping long or variable-length goods

Industrial parts distribution

Distributors shipping long metal or plastic components often struggle with fixed box sizes. This four-piece system provides a stackable alternative to round tubes, keeping the package from rolling on sorting conveyors.

Large-format print and graphics

For oversized posters or banners, the rectangular profile is easier to palletize than round tubes. The finger-pull hole in the end caps allows the recipient to remove the closure without digging into the corrugated board or damaging the rolled print inside.

Architectural hardware and fixtures

Long, narrow items like curtain rods or metal extrusions often vary in length by a few inches. The sliding tubes accommodate these variations without requiring custom inserts or excessive void fill.

When to compare fixed-length or tray-cap boxes

High-volume packing lines

If you are packing thousands of identical long items, the manual labor of folding four separate end-cap flaps and sliding two tubes together will slow down fulfillment. A fixed-length box or a wrap-around blank is much faster for predictable, high-volume runs.

Heavy parcel shipping without strapping

Friction-fit end caps can blow out if a heavy item shifts during rough courier handling. If you cannot strap the ends securely, consider a telescopic box that uses deeper, tray-style end caps, which are often more secure under axial load.

Board thickness, sliding clearance, and packing labor

Board thickness and sliding clearance

The gap between the inner and outer tubes should be precisely tuned to your chosen board grade. If the board is too thick or the gap too tight, the tubes will bind during assembly. If the gap is too loose, the package loses rigidity. This clearance should always be tested with a physical prototype.

Fulfillment center readiness

This package arrives as four flat pieces: two glued tubes that open into shape, and two flat pads that are manually folded into plugs. Your packing team should budget time to fold the end caps, slide the tubes together, and apply external strapping.

Parcel sealing strategy

Because the tubes are built to slide, they will separate during transit if not secured. Packers apply external packing tape or plastic strapping across the seam where the two tubes meet, as well as over the end caps to reduce the risk of the product pushing through.

Overlap length for crush resistance

The section where the outer tube overlaps the inner tube provides double-wall protection. For maximum crush resistance, the outer tube can be sized to cover the majority of the inner tube's length, though this limits the maximum extended length of the package.

Adjusting the end caps and tube overlap

End cap plug depth

The depth of the friction-fit flaps can be extended. Deeper flaps provide more surface area against the inner tube walls, increasing the friction hold and helping the cap stay square under pressure.

Finger hole sizing

The central cutout on the end caps provides a grip for easy removal. This diameter can be adjusted based on whether the end user will be wearing work gloves or if the product requires a smaller opening to reduce dust ingress.

Inner and outer tube length ratio

The relative lengths of the two tubes can be adjusted. A longer outer tube provides more double-wall overlap for crush resistance, while a shorter outer tube maximizes the total adjustable length of the assembled package.

Packing details

Securing the sliding tubes for transit

Additional notes

Double-wall overlap strength

The section where the outer tube overlaps the inner tube provides double-wall protection. For maximum crush resistance, the outer tube can be sized to cover the majority of the inner tube's length.

FAQs

How is the final length secured for shipping?

Because the tubes are built to slide, courier handling will cause the pieces to separate if they are not secured. Packers apply external packing tape or plastic strapping across the seam where the two tubes meet, as well as over the end caps to reduce the risk of blowouts.

How is this package delivered to the fulfillment center?

It arrives flat as four separate pieces. The two main tubes are pre-glued on the side seam and pop open. The two end caps arrive as flat pads that are manually folded into shape before insertion.

Can the sliding tubes bind or get stuck?

They can if the clearance gap between the inner and outer tube is not matched to the board thickness. Prototyping the exact board grade helps ensure the tubes slide smoothly without being too loose.

Is this better than a round mailing tube?

Rectangular tubes will not roll off sorting belts or warehouse shelves, making them easier to palletize and stack. The double-wall overlap also provides crush resistance for heavy items.

Can we remove the finger hole on the end caps?

The hole can be removed or resized. However, without the hole, the friction-fit end caps can be very difficult for the end user to pull out, especially if they are wedged tightly against the product.

Will the end caps hold heavy industrial parts?

Heavy parts shifting during transit can act like a battering ram against the end caps. For dense items like metal shafts, the end caps often need heavy strapping, or you may need to compare a design with fully overlapping tray caps.

How much crush resistance does the overlap provide?

The overlapped section acts as a double-wall board, increasing vertical strength. Sizing the outer tube to cover more of the inner tube will maximize this reinforced area.

Can we print on both the inner and outer tubes?

Yes, but the outer tube will cover part of the inner tube depending on the final extended length. Critical branding or handling instructions should be placed on the outer tube to ensure they remain visible.
