EVC62081

Multi-Shelf Corrugated Floor Display with Dividers

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Multi-part kit including a base, holder, shelves, and dividers
Freestanding pedestal elevates products to shopping height
Requires manual assembly and a master shipper for transit

About this product

This freestanding corrugated floor display is designed for retail environments, offering a structured way to present multiple products or SKUs. It uses a tall pedestal base to elevate an angled upper holder, which supports individual shelves divided into smaller compartments.

Because it is a multi-part kit relying on tab-and-slot connections, it requires manual assembly and is typically shipped flat to a co-packer or retail location before being loaded with goods.

Common uses

Multi-SKU product launches
lightweight consumer goods
seasonal retail promotions

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall display width

Overall display depth

Overall display height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How will this display be assembled and loaded with product?

What type of products will be placed on the shelves?

Do you have a specific number of shelves or compartments in mind?

Which areas of the display will require custom printing?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail and Point-of-Purchase Applications

Multi-SKU retail floor promotions

The divided shelves naturally separate different product variations, flavors, or sizes, making it easier for shoppers to browse a complete product line in one freestanding footprint.

Lightweight boxed or packaged consumer goods

The tab-and-slot shelf connections are well-suited for packaged snacks, cosmetics, small electronics, or boxed retail items. Heavy liquids or dense hardware may require a different structural approach or reinforced board.

Seasonal or temporary product launches

The freestanding nature allows temporary placement in high-traffic aisles without permanent fixtures.

Co-packed retail assortments

The divided shelves make it easy for co-packers to load mixed assortments into a single display unit.

Merchandising and Fulfillment Scenarios

Co-packing and retail fulfillment

Since the display consists of multiple flat components (base, holder, trays, and carriers), it is typically delivered knocked-down to a co-packer. The co-packer assembles the display, loads the product, and places the entire unit into a master shipper for retail distribution.

Store-floor manual assembly

If shipped flat directly to retail, store staff will need to follow a multi-step assembly process. The base pops open easily, but the upper holder, shelves, and dividers require careful tab-and-slot alignment.

End-cap or aisle-end merchandising

The tall pedestal base elevates the product to eye level, making it suitable for end-of-aisle placement where visibility is key.

When to Consider Alternative Displays

When countertop presentation is preferred

If floor space is limited or the product volume is small, a multi-shelf counter display provides a similar organized presentation without the large pedestal base.

When faster retail setup is required

If store staff cannot dedicate time to multi-part assembly, consider a pre-assembled display shipper or a simpler dump bin that requires fewer folding steps.

Key Decisions Before Production

Shelf quantity and compartment width

The number of vertical shelves and horizontal compartments can be adjusted to match your product dimensions and total required inventory. Changing these counts will alter the overall height and width of the display.

Board strength and mixed material choices

The pedestal base often requires a heavier board grade to support the total weight of the loaded upper section. The shelves and dividers can sometimes use a lighter board to reduce cost and make folding easier, provided the tab-and-slot clearances are adjusted accordingly.

Visible print panels and graphic placement

Determine which components need graphics. Typically, the outside of the base, the inside and outside of the angled holder, and the front lips of the shelves are the primary visible areas.

Kitting and flat-pack delivery

Deciding whether the manufacturer will collate the base, holder, shelves, and dividers into a single master shipper for the co-packer.

Structural Adjustments and Options

Shelf front lip height

The front wall of each shelf can be raised to provide more branding space or better product retention, or lowered to increase product visibility and access.

Header panel integration

While the base template features an angled back, a separate header panel can often be integrated or added to the top of the holder for additional promotional messaging.

Divider removal or adjustment

The slotted level carriers can be adjusted in quantity to change the width of the compartments on each shelf.

Packing details

Master shipper requirements for flat transit

This display cannot be shipped through parcel networks once assembled. The flat components must be kitted into a dedicated outer corrugated shipper for transit to the co-packer or retail store.

Physical load testing for tab-and-slot shelves

Because the shelves rely on tabs inserted into the side walls of the holder, physical load testing with the actual product and chosen board grade is strongly recommended to ensure the shelves do not shear or sag over time.

Additional notes

Kitting and flat component collation

Because the display consists of multiple separate pieces, the manufacturer will need to collate and kit the base, holder, trays, and dividers into a single flat package for delivery.

Center of gravity and forward tipping risk

When adjusting the shelf depth, ensure the upper holder is not made so deep or loaded so heavily that it causes the entire freestanding tower to tip forward.

FAQs

How is the display assembled?

The base is supplied as a pre-glued tube that pops open. The angled holder folds and tabs into the top of the base. The individual shelves are folded and tabbed into the holder's walls, and the dividers slot into the shelves. It requires manual assembly.

How much weight can the shelves hold?

Weight capacity depends entirely on the chosen board grade and the exact dimensions of the display. Because the shelves are supported by tabs locking into the side walls, heavy items may cause the tabs to shear. Physical testing with your product is necessary.

Can all parts of the display be printed?

While any flat component can be printed, graphics are usually focused on the most visible areas: the pedestal base, the back and sides of the holder, and the front lips of the shelves. Internal dividers often remain unprinted to manage costs.

Can this display be shipped fully assembled?

This structure is not intended for single-unit parcel shipping once assembled and loaded. It is typically shipped flat in a master shipper to a co-packer, or assembled, loaded, and palletized for dedicated freight transport.

Can I change the number of compartments on each shelf?

The template allows for adjusting the number of vertical dividers. Modifying this changes the number of compartments per shelf and the overall width of the display to fit specific product sizes.

Do the base and the shelves have to be the same material?

It is common to use a stronger, thicker board for the load-bearing pedestal base and a slightly thinner board for the shelves and dividers to make folding easier. If mixed materials are used, the connecting slot widths must be adjusted to match the specific board thicknesses.

What is the purpose of the tall pedestal base?

It elevates the angled holder and shelves to a comfortable shopping height without requiring a retail table or counter.

How are the shelves secured to the main display?

The shelves use locking tabs that insert into corresponding slots on the side walls of the angled holder.
