EVC62202

Two-Step Corrugated Magazine Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Two slanted steps for magazines or brochures
Separate friction-fit header board for branding
Tool-free manual assembly with tab-and-slot locks

About this product

This freestanding corrugated floor display is designed specifically for magazines, brochures, and flat promotional media. The front panel articulates inward to form two distinct, slanted steps that present literature at an accessible angle for retail aisles or end-caps.

Delivered flat to retail locations, the display is assembled manually without tools or adhesive. A separate header board slots into the top back wall, providing a dedicated space for branding that can be swapped out for different campaigns.

Common uses

Retail end-caps
Trade show literature stands
Bookstore promotional displays

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Step width

Step depth

Header height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What type of media will this display hold?

How will you use the removable header?

How will the displays be shipped to their final location?

Where will the display be placed?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail and Promotional Display Uses

Magazine and Brochure Merchandising

The slanted, two-step profile is tailored for stacking flat media. The steps keep literature organized and visible, making it a strong fit for bookstores, newsstands, and promotional literature distribution.

Trade Show and Event Literature

Because it ships completely flat and requires no tools to erect, this display is very practical for temporary event spaces where staff need to set up and break down quickly.

Promotional Book Releases

The angled presentation works well for presenting new paperback or hardcover releases, keeping the cover art fully visible to passing foot traffic.

Retail Catalog Distribution

For seasonal catalogs or store guides, the deep steps provide enough capacity to hold thick stacks of printed material without constant restocking.

Retail Environments and Channels

Retail End-Caps and Aisles

The tall back wall and prominent header draw attention in busy retail environments, while the compact footprint allows it to sit flush against end-caps or stand independently in wide aisles.

Bookstore and Newsstand Promotions

The dedicated step design fits naturally into environments already focused on printed media, providing a temporary, branded home for special editions or publisher campaigns.

Trade Show Booths and Lobbies

The tool-free assembly and flat-shipping format make it easy to deploy in corporate lobbies or exhibition spaces to distribute informational packets.

When to Consider Different Display Styles

Heavy Hardgoods or Bottled Products

This display relies on step side tabs to carry the product load. If you are merchandising heavy items like beverages or hardware, a display with reinforced, independent shelf boards or a closed, load-bearing base is a safer choice.

Multi-Product Assortments

If your campaign requires merchandising different product sizes on three or four shelves, look at standard multi-shelf floor displays rather than a two-step magazine stand.

Key Decisions for Specification

Board Grade and Product Weight

The weight of stacked magazines adds up quickly. While B-flute provides a good starting point, heavy catalogs or thick brochures may require C-flute or double-wall board to prevent the step tabs from tearing under shear load.

Header Printing Strategy

The header is cut as a separate piece. You can choose to print it on the same sheet as the main body, or run it separately. Running headers separately allows you to produce multiple graphic versions for different promotions while using the same base display.

Floor Moisture Protection

The display features an open bottom skirt that rests directly on the retail floor. If the display will be placed near entrances or in environments prone to wet mopping, discuss moisture-resistant coatings for the bottom edges.

Kitting and Fulfillment Route

Decide whether the display will be shipped flat to stores for local assembly, or if it will be pre-assembled and kitted with the magazines at a fulfillment center before transit.

Structural Adjustments

Step Depth and Height

The depth of the treads and the height of the risers can be adjusted to match the specific dimensions of your magazines or brochures, ensuring they sit securely without tipping forward.

Display Slant Angle

The overall bevel angle of the front face can be modified. A steeper angle saves floor space, while a shallower angle provides a more relaxed presentation, though extreme angles should be checked for tipping risk.

Header Profile and Size

Because the header is a separate flat board, its outer shape can be die-cut to match brand logos or campaign themes without altering the main display body.

Packing details

Flatbed Die-Cutting Recommendation

The intricate tab-and-slot connections that form the steps require precise cutting. Flatbed die-cutting is generally recommended over rotary methods to ensure the locking tabs engage cleanly during in-store assembly.

Additional notes

In-store assembly labor

Retail staff must fold the main tube, articulate the steps, and lock multiple tabs into place. While tool-free, it requires a few minutes of focused assembly per unit.

Tipping risk with heavy top loads

The depth of the side walls provides stability, but placing excessively heavy catalogs only on the top step can shift the center of gravity. Load distribution should be considered during sizing.

FAQs

Does this display require glue or tape to set up?

No. The main body folds into a tube secured by tuck tongues, and the steps are formed by pushing the front panel inward and locking side tabs into the walls. The entire assembly is manual and tool-free.

How much weight can the two steps hold?

The load capacity depends entirely on the chosen corrugated board grade. Because the weight is carried by the side tabs of the steps, heavy magazine stacks usually require a stronger C-flute or double-wall material. We recommend physical testing with your actual media.

How is the top header attached?

The header is a separate flat board with vertical slits at the bottom. It slides into corresponding slits at the top of the display's back wall, creating a secure friction fit.

How is this display shipped to stores?

Both the main body and the header board are delivered completely flat (knocked down). They must be packed inside a separate outer shipping carton for parcel or freight transit to the retail location.

Can I add a closed base to this display?

This specific template is designed with an open bottom skirt. If your retail environment requires a closed, load-bearing base, it is usually more practical to select a different floor display template rather than heavily modifying this open-bottom design.

Can the header be printed differently than the base?

Yes. Because the header is a separate piece, it can be printed with different graphics or even on a different material, making it easy to update seasonal promotions while keeping the main display body the same.

Can the steps be divided to hold smaller brochures side-by-side?

Yes. The template can be modified to include internal divider tabs, allowing you to present multiple stacks of narrower brochures on the same step without them sliding together.

Should we test the display with actual magazines before ordering?

Yes. Testing a physical prototype with your exact magazines is crucial to verify that the center of gravity remains stable and that the step tabs can handle the shear weight of the paper stacks.
