EVC62821

Modular Corrugated Display Cell

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Thick hollow walls with clean mitered corners
  • Stacks and connects using separate locking clips
  • Ships flat for manual in-store assembly

About this product

The EVC62821 is a modular corrugated display component that folds into a thick-walled, open-faced cubby. Designed for retail environments, these cells stack and connect to build custom floor displays, pigeon-hole shelving, or freestanding product walls.

Because the walls are hollow and formed by rolling the corrugated board inward, the final unit looks substantial and bears vertical weight well while still shipping completely flat. A separate locking clip secures the assembled shape and bridges adjacent cells together.

Common uses

  • Pigeon-hole retail shelving
  • Modular floor display walls
  • Lightweight trade show cubbies
  • Window display staging

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Display And Shelving Configurations

Modular floor display walls

Multiple cells can be stacked and locked together to create freestanding product walls. The thick buffer walls provide the vertical strength to support stacked units, making it easy to build large, segmented displays from a single repeating component.

Pigeon-hole retail shelving

With both the front and back faces open, this cell works well for accessible, multi-sided shelving. It allows shoppers to view and reach products from multiple angles when placed in aisles or open floor spaces.

Trade show and pop-up shop cubbies

Because the components ship flat and assemble without tools, they are useful for temporary event fixtures. Exhibitors can build custom shelving configurations on-site and break them down after the event.

Window display staging

The open front and back allow natural light to pass through the display. This makes the cell a strong fit for storefront windows where solid-backed shelving would block visibility into the main retail space.

Merchandising And Store Rollouts

In-store merchandising programs

Because the cells ship completely flat, they minimize freight volume for national retail rollouts. Store staff can assemble the planned number of cells on-site and configure them to fit the available floor space.

Temporary event and exhibition builds

Event teams often need lightweight, structural shelving that does not rely on heavy wood or metal fixtures. These corrugated cells provide a thick-walled appearance while remaining easy to transport and recycle.

Brand activation pop-ups

Short-term retail spaces benefit from modular components that can adapt to different room layouts. The separate locking clips allow the cells to be arranged in various grid patterns depending on the venue.

When To Consider Simpler Display Trays Or Shippers

High-speed fulfillment packing

This cell involves multiple manual folding steps, including pre-breaking scores, rolling the hollow walls inward, and aligning mitered corners. If the display is loaded and sealed at a fulfillment center rather than built in-store, a standard stackable tray or a pre-glued display shipper is often a better choice.

Direct parcel shipping

This is an open-faced structural component, not a protective shipper. If the unit travels through a courier network, it usually needs an outer master carton to protect the contents and the display itself.

Board Caliper, Assembly Labor, And Locking Clips

Board thickness and miter fit

The 45-degree mitered corners and the separate locking clips rely on exact board thickness to fit cleanly. Changing the flute profile means adjusting the template clearances so the corners close without bowing and the clips slide on without tearing.

Lock clip nesting

The main cell blank is a large cross shape, which naturally creates empty space on the corrugated sheet during production. The small, separate locking clips can often be nested into these waste areas to optimize material use.

In-store assembly time

Forming the thick buffer walls takes multiple precise folds. Buyers should plan for the manual labor involved at the retail level and consider providing printed assembly instructions to ensure the corners are squared correctly.

Print surfaces and orientation

Graphics can be applied to the outer perimeter and the inner rolled walls. Because the inner walls are formed by folding the top and bottom extensions inward, the artwork layout should account for these panels rotating into position during assembly.

Adjusting Wall Thickness And Cell Depth

Wall thickness (Buffer Wall)

The thickness of the hollow frame can be adjusted to change the visual weight of the display. Thicker walls look more substantial and increase the overall footprint, but they should be balanced against the size limits of the die-cutting equipment.

Cell depth and opening size

The internal width, height, and depth can be scaled to fit specific products. Deeper cells provide more shelf space but increase the overall size of the flat blank.

Locking clip slot sizing

The U-shaped slot on the separate locking clip is tied directly to the board caliper. If the material changes, this slot width is adjusted so the clip grips the perimeter tabs firmly without crushing the flute.

Packing details

Prototyping the miter joints

Because the corner fit is highly sensitive to the exact corrugated material, it is best to cut a physical sample from the final production board to verify the folds before running a full order.

Related Retail Display Components

FAQs

How are the display cells connected?

Each cell has small tabs on its outer perimeter. A separate corrugated locking clip, which features a U-shaped slot, slides over the tabs of adjacent cells to bridge them together and prevent the stack from shifting.

Can this display be assembled automatically?

The design relies entirely on manual folding. The hollow walls are rolled inward by hand, and the corners are aligned before the final tuck tongue is inserted.

How much weight can the stacked cells hold?

The vertical strength comes from the thick, hollow buffer walls. While they bear weight well, the exact capacity depends on the chosen board grade, the overall size of the cell, and the humidity of the retail environment. Physical testing helps confirm limits for heavy products.

Can I ship products inside the assembled cell?

The cell has open front and back faces and no native sealing mechanism. If products are pre-loaded, the entire assembly usually goes inside a protective outer shipper for transit.

Why is board thickness so critical for this design?

The template uses 45-degree angled cuts to form clean corners when the walls are rolled inward. If the board is thicker or thinner than planned, these mitered corners can gap or bind, and the locking clips might not fit over the perimeter tabs.

Do I need glue to assemble the cell?

The cell holds its shape using a mechanical tuck tongue that inserts into a corresponding slot, and the separate clips lock the overall display together without adhesive.

Can the locking clips be printed?

Yes, the separate locking clips can be printed. Because they are often nested in the waste areas of the main cell blank, they typically share the same print run and board grade as the main display.

How does the open back affect display placement?

The two-face open design allows shoppers to see through the shelving, making it useful for center-aisle placements or window displays where light transmission is helpful.
