Interactive 3D

1 / 3

EVC62903

Slanted Peg Hook Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Four-piece tab-and-slot construction
Slanted profile for improved hanging stability
Requires manual assembly and hook insertion

About this product

The EVC62903 is a freestanding, multi-piece corrugated floor display designed for hanging merchandise. Featuring a slanted back profile, a dedicated hook panel, and a rectangular base pedestal, it provides high visibility for blister-packed or bagged goods in retail aisles and end-caps.

Because the display is built from four separate corrugated components (base, body, hook board, and header), it offers excellent structural stability but requires dedicated assembly time. The separate hook board allows for flexible peg arrangements while the angled chassis shifts the center of gravity backward to help prevent tipping.

Common uses

Blister-packed electronics
Bagged snacks
Retail end-caps
Hardware accessories

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall display width

Overall display height

Base footprint depth

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

Do you already have the peg hooks you plan to use?

How will this display be assembled and shipped?

What is the estimated total weight of the hanging products?

Which parts of the display will need custom artwork?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Environments and Hanging Merchandise

Blister-Packed Electronics and Hardware

This package is built specifically for items that hang on peg hooks, such as charging cables, phone cases, or small tools. The slanted back ensures that products cascade neatly and remain visible, while the separate hook panel provides a rigid mounting surface.

Bagged Snacks and Confectionery

For lightweight hanging bags, the hook grid can be spaced closely together to maximize inventory. The roll-over base tray elevates the bottom row of products off the floor to protect them from foot traffic and cleaning equipment.

Freestanding Retail End-Caps

With a sturdy roll-over base tray, the unit elevates merchandise off the floor and provides a stable footprint. It is designed to stand alone in high-traffic retail zones without relying on existing store shelving.

Heavy or Dense Hanging Merchandise

Because the hook board is a separate corrugated piece that nests into the main chassis, it can be cut from a heavier double-wall board to resist tearing, even if the rest of the unit uses a lighter grade.

Fulfillment and Assembly Planning

Co-Packing and Fulfillment Planning

Because this unit consists of four corrugated blanks plus third-party hooks, assembly labor is a major factor. Brands often choose to have a co-packer assemble the unit and load the merchandise, shipping the entire build in a reinforced master carton.

Store-Level Assembly

If shipped flat to retail locations, store staff will need clear instructions to erect the base, mount the body, insert the hooks, and attach the header. The multi-piece design requires more time to set up than a single-piece pop-up unit.

Brand-Controlled Merchandising

When relying on existing store pegs is not an option, this freestanding unit allows brands to dictate the exact presentation, hook spacing, and product grouping in the aisle.

When to Consider Alternative Displays

Countertop or Shelf-Ready Needs

If your product volume is low or floor space is unavailable, a smaller countertop hook unit or a shelf-ready tray is a better fit. This large footprint is strictly for high-volume floor placement.

Single-Piece Pop-Up Units

If minimizing store labor is the primary goal, review single-piece easel units that fold out quickly. The tradeoff is that single-piece units often cannot support the same weight or hook density as this multi-piece chassis.

Key Decisions for Display Specification

Hook Hardware Sourcing

The exact dimensions and wire gauge of your physical peg hooks must be known before manufacturing. The hook slots on the corrugated panel are cut to match your specific hardware to prevent tearing and ensure a snug fit.

Board Grade and Product Weight

Hanging heavy items concentrates stress on the hook slots. The hook panel and main body often require a heavier double-wall board to prevent tear-out, while the header might use a lighter grade for better print quality.

Delivery Method and Master Shippers

Decide early whether the unit will ship flat or fully assembled. Fully loaded units require a heavy-duty outer corrugated shipper to protect the merchandise and keep the hooks from tearing the board during transit.

Print Coverage Across Components

Because the base, body, hook panel, and header are cut from separate blanks, you can choose which parts receive high-quality printing. Many brands leave the hook panel plain or flood-coated, focusing detailed artwork on the header and base.

Configuring the Hook Grid and Profile

Hook Grid Layout

The number of hooks and the distance between them can be adjusted to match your product width and height. Dense grids allow for more inventory but reduce the overall strength of the corrugated panel.

Slant Angle and Base Footprint

The backward slant of the unit can be steepened or shallowed. However, changing this angle shifts the center of gravity, which usually requires adjusting the depth of the base tray to maintain tipping resistance.

Header Card Profile

The top header can be sized independently of the main body to accommodate different branding requirements or die-cut shapes, as long as the bottom tabs still align with the main chassis.

Packing details

Master Shipper Requirements

This unit cannot be shipped through parcel networks on its own. Whether shipping flat to a distribution center or fully loaded from a co-packer, it requires a dedicated outer corrugated shipper for protection.

Additional notes

Center of Gravity and Tipping

The slanted design naturally pushes the weight of the hanging products backward, improving stability. If you request a steeper vertical angle, the base footprint must be extended to prevent forward tipping.

FAQs

How difficult is this unit to assemble?

It requires moderate to high manual effort. The process involves erecting the base tray, folding the main body, manually inserting all peg hooks into the flat panel, nesting the loaded panel into the body, and attaching the header.

Do I need to supply the peg hooks?

Peg hooks are third-party hardware. You can source them independently or work with your packaging partner to kit them. In either case, the exact hook dimensions are required early in the design process to cut the correct slot sizes.

How much weight can the unit hold?

Weight capacity depends entirely on the chosen board grade and the hook density. Heavy items require rigid, double-wall corrugated board to prevent the hook slots from tearing. We recommend physical load testing with your actual products.

Can this unit be shipped fully assembled with products?

Yes, but it requires a heavy-duty, reinforced outer master shipper to protect the unit and keep the hooks from tearing the board during transit. Many brands prefer to ship the unit flat to stores to reduce freight costs.

Can we add shelves to this hook unit?

Adding shelves changes the load-bearing mechanics entirely. If you need a mix of shelves and hooks, it is usually better to start with a dedicated hybrid template rather than modifying this specific hook-only chassis.

Where does the artwork go on this unit?

The primary branding areas are the removable top header, the front-facing base tray, and the side walls of the main body. The hook panel itself can also be printed, though it is largely covered by merchandise.

Can we change the hook layout for different seasons?

The hook slots are permanently cut into the corrugated panel. If you need a different layout for a new product line, you will need a newly manufactured hook panel, though the base and body might remain the same if the overall dimensions fit.

Why is the hook panel a separate piece?

A separate flat panel is much easier to load with hooks and merchandise than a pre-folded box. It also allows you to use a heavier, stronger board just for the hook section while using standard board for the rest of the chassis.
