EVC62991

Automatic Pop-Up Totem Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Pops open via internal tension
Double-sided convex billboard surface
Ships flat for efficient distribution

About this product

The EVC62991 is a freestanding, double-sided corrugated totem display designed for high-impact retail marketing. It forms a tall, convex column that provides a continuous curved billboard surface for promotional graphics.

To reduce assembly errors at the store level, this display relies on internal support struts and elastic bands. It ships flat and automatically pops open into its rigid elliptical shape when the edges are pushed inward, requiring minimal training for retail staff.

Common uses

Retail end-caps
Cinema lobbies
Trade show signage

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Width

Height

Depth

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

Where will this display be placed?

Will the display sit on a floor that gets mopped frequently?

What is the status of the artwork for the curved panels?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail And Promotional Signage

Point-of-Sale (POS) Floor Displays

Useful for retail end-caps, aisles, and entryways where large, freestanding visibility is needed. The continuous curved faces draw attention from multiple angles without the sharp corners of a folded square column.

Trade Show And Event Signage

Because it ships flat and sets up quickly, it is effective for temporary event marketing and trade show booths where fast deployment is critical.

Cinema and Entertainment Lobbies

The tall, double-sided profile provides a large canvas for movie promotions and entertainment marketing, standing out in crowded lobby environments.

Supermarket End-Caps

Fits well at the end of grocery aisles to promote seasonal campaigns, offering high visibility without taking up valuable shelf space.

Campaign Distribution And Store Execution

National Retail Campaigns

For brands distributing displays to hundreds of stores, the pop-up mechanism helps ensure the display is actually used. Store staff do not need to fold complex corrugated structures or read assembly instructions.

High-End Graphic Presentations

The large, uninterrupted front and back panels are well-suited for litho-lamination or high-quality digital print. Using a finer board, such as E-flute, minimizes visible flute lines on the curved surface.

Temporary Promotional Cycles

Useful for short-term campaigns where fast setup and teardown matter. The corrugated construction is durable enough for a promotional window while remaining easy to recycle afterward.

When To Consider A Different Display Style

Holding Physical Products

This totem is designed as a signage structure. It lacks horizontal load-bearing shelves. If the display needs to hold merchandise, a tiered floor stand or dump bin is usually a better fit.

Rigid Permanent Signage

While durable for promotional cycles, corrugated board can dent if struck. For permanent or high-traffic semi-permanent fixtures, a rigid board or plastic structure may be worth comparing.

Production And Structural Choices

Pre-Glued Assembly vs. Retail Labor

The fast retail setup shifts the assembly burden to the production stage. The converter glues the internal struts, seals the side seams, and threads the elastic bands before shipping. This upfront preparation helps ensure a foolproof setup at the retail store.

Board Grade And Flute Direction

The corrugated flutes usually run vertically so the main panels can bow smoothly into an ellipse without creasing. B-flute offers a good balance of flexibility and standing rigidity, while E-flute provides a smoother print surface.

Moisture Protection At Retail

Because the raw bottom edge rests directly on the floor, it is vulnerable to mop water and scuffing. Discuss adding a clear plastic base tray or moisture-resistant coating if the display will sit in high-traffic retail aisles.

Print Surface and Coating

The large, uninterrupted front and back panels are well-suited for litho-lamination or high-quality digital print. A protective varnish or coating can help prevent scuffing during transit and retail handling.

Sizing And Stability Adjustments

Internal Support Count

The number of internal struts can be adjusted based on the overall height of the totem. Taller displays often use more struts to maintain the convex shape and prevent the faces from flattening or buckling.

Footprint And Curve Depth

The width and depth of the ellipse can be modified. A wider display provides more billboard space but requires a larger footprint and may need stiffer internal tension to hold its shape.

Elastic Tension and Band Routing

The size and placement of the internal routing holes can be adjusted to match the specific elastic bands used, ensuring the display pops open consistently based on the chosen board grade.

Packing details

Large-Format Production Limits

A standard totem can be 1800mm (nearly 6 feet) tall. This often uses large-format flatbed die-cutting equipment and oversized printing capabilities. Very large displays may need to be spliced if they exceed machine envelopes.

Additional notes

Vertical flute direction

The structural integrity and smooth curve of the display rely on the corrugated flutes running vertically. Horizontal flutes would cause the faces to crease rather than bow.

FAQs

How does the display pop open?

Internal support struts are glued to the inside faces and connected by elastic bands. When the flat display is pushed at the edges, the elastics pull the struts into an angled position, locking the curved shape in place.

Does it need tools to assemble?

No. The internal struts and bands are pre-assembled before shipping. Retail staff simply remove it from the shipping carton and push the sides inward to erect it.

Can it hold physical products?

The curved faces and internal tension mechanism are designed for signage. If you need to hold physical products, a tiered floor stand or dump bin is usually a better fit.

How is the display shipped?

Despite its large assembled size, the display folds flat. It is typically shipped in a thin, flat corrugated master carton.

Will the corrugated flutes be visible on the graphics?

Because the board is bowed under tension, flute lines can sometimes be seen on glossy prints. Using a finer E-flute instead of B-flute helps minimize this effect.

How does the pre-glued mechanism affect production?

The internal mechanism involves specialized gluing and manual insertion of elastic bands before shipping. This upfront preparation helps ensure a foolproof, zero-labor setup at the retail store.

Can the height of the display be adjusted?

Yes, the overall height can be modified. Taller displays usually require additional internal support struts to maintain the convex shape and prevent the faces from flattening.

What board grade makes sense for this display?

B-flute offers a good balance of flexibility and standing rigidity, while E-flute provides a smoother surface for high-end graphics. The choice depends on the print requirements and the overall size of the totem.
