EVF48002

Octagonal Double-Wall Presentation Tray

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Eight-sided framed presentation with hollow double walls
Glueless foot-lock assembly requires manual folding
Delivered flat to reduce inbound freight and storage space

About this product

The EVF48002 is an eight-sided paperboard tray featuring thick, hollow double walls that create a rigid, framed border around the product. Designed for premium retail and gift packaging, it elevates the perceived value of cosmetics, confectionery, and specialty assortments without requiring glued seams.

Because the double walls radiate in all eight directions, this tray requires a multi-step manual folding sequence to lock the perimeter into the base. It is a strong choice for high-end programs where the unique octagonal presentation justifies the assembly time and larger material footprint.

Common uses

Luxury confectionery assortments
High-end cosmetics and skincare kits
Premium retail gift sets

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Inside length

Inside width

Inside depth

Size notes

Quantity notes

Materials and print

Paperboard preference

Add details for paperboard preference

Paperboard details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How will this tray be assembled and packed?

How will the finished tray be closed or shipped?

Do you plan to print on the inside walls of the tray?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Premium Retail and Gift Presentation

Framed retail displays

The hollow walls create a thick border that draws attention to the center cavity, making it a natural fit for high-end retail environments. The rigid perimeter resists side impacts and keeps the tray stable when handled by customers.

Unglued gift sets

The entire tray locks together using friction and base tabs. This eliminates glue seams, providing a clean, uninterrupted interior that works well for luxury assortments and unboxing experiences.

High-end confectionery assortments

The hollow walls provide a protective buffer and a premium frame for delicate chocolates or truffles, keeping the product centered and secure.

Specialty cosmetics and skincare kits

The rigid perimeter and clean interior elevate the unboxing experience for premium beauty products, offering a distinct shape that stands out from standard packaging.

Confectionery, Cosmetics, and Specialty Kits

Premium retail environments

The octagonal shape stands out on shelves dominated by standard rectangles. The wide top rim provides an excellent surface for continuous graphics, foil stamping, or brand messaging directly framing the product.

Dedicated hand-packing operations

This tray is delivered flat and erected entirely by hand. Packing teams must fold the four corner walls first, followed by the four main walls, rolling the inner panels down to lock the tray. It fits operations equipped for hand assembly rather than high-speed automated forming.

Low-to-medium volume promotional runs

Because the eight-sided locking sequence requires manual labor, this tray often fits promotional or seasonal programs where the unique presentation justifies the assembly time.

Rectangular Trays and Automated Alternatives

High-speed packing operations

The eight-sided locking sequence is complex for standard automated tray formers. If the packing line relies on mechanization, a standard four-sided glued tray or a machine-erected crash-lock base may be a better fit.

Material-efficient programs

The flat blank for this tray is star-shaped, which leaves offcuts on the sheet. If material efficiency is the primary driver, a standard rectangular double-wall tray will nest more closely during production.

Board Caliper, Print Surface, and Assembly Labor

Board thickness and lock seating

The inner walls are sized to account for the exact thickness of the paperboard. If the board is too thick, the foot-locks will bind and fail to seat in the base. The material caliper must be finalized early in the specification process.

Grain direction and rim cracking

The top rim requires a crisp 180-degree fold. Because the tray is octagonal, some folds will inevitably cross the grain of the board. Selecting a high-quality folding boxboard helps prevent the printed edges from cracking during assembly.

Secondary shipping packaging

This template provides the base tray only. For parcel or courier delivery, it will require a matching octagonal lid, a custom sleeve, or a protective outer shipping box.

Print surface and interior presentation

The glueless design means there are no unprinted glue flaps interrupting the interior. Buyers should decide whether to print the inner walls to match the exterior or leave them plain.

Adjusting the Octagon Shape and Wall Proportions

Modifying the corner angles

The bevel angle of the four corner walls can be adjusted to create a more elongated or more uniform octagon. Extreme angle changes must be checked to ensure the folding side flaps do not collide during assembly.

Wall height and footprint

The overall length, width, and height can scale to fit the product. Taller walls increase the overall size of the flat blank, which changes how the tray fits on a production sheet.

Top rim width

The width of the hollow walls can be expanded to create a thicker frame around the product, though this increases the overall flat footprint.

Packing details

Assembly training and prototypes

Because the folding sequence requires trapping the corner flaps inside the main walls before locking the base, fulfillment teams should review a physical prototype. Reviewing a physical prototype helps confirm the packing rhythm and labor time before a full rollout.

Additional notes

Print panel and scuff risk

The hollow outer walls and top rim are highly visible. If the tray will be stacked or slid into a tight sleeve, consider a protective varnish or coating to prevent ink scuffing on the corners.

FAQs

Can this tray be erected on automated packing equipment?

The multi-phase folding sequence, which requires rolling eight separate walls over interlocking corner flaps, is designed for manual assembly rather than standard automated tray formers.

Does the tray require glue or tape to stay together?

The inner walls wedge against each other and lock into the base panel using friction tabs, creating a rigid tray without adhesives.

Can I use a thicker corrugated micro-flute for this tray?

Switching from standard paperboard to a thicker micro-flute requires careful CAD adjustments. The added thickness changes how the 180-degree rim folds behave and can prevent the base locks from seating properly.

Is this tray ready for parcel shipping?

It is an open presentation tray. For parcel shipping, it will need a separate lid, sleeve, or outer shipping carton to protect the contents.

Can the width of the hollow walls be adjusted?

The top rim width can be widened to create a thicker frame around the product, though this increases the overall footprint of the flat blank.

Where can graphics be printed on this tray?

The entire exterior, the wide top rim, and the inner walls can be printed. The glueless design means there are no unprinted glue flaps interrupting the interior presentation.

How is this tray delivered?

The tray is delivered flat. It must be erected by hand before loading the product.

What products fit well in this tray?

It is often used for premium confectionery, cosmetics, and specialty gift sets where the octagonal shape and thick framed walls enhance the presentation.
