EVC62002

Three-Tier Slanted Shelf Floor Display

The EVC62002 is a freestanding corrugated floor display featuring three angled shelves and a tall branding header. Designed for retail environments, the downward slant improves product visibility and can act as a gravity feed for boxed or cylindrical items.

This multi-piece unit consists of a sturdy pedestal base, a main body, and three separate shelves. The components ship flat and lock together at the retail store using a secure tab-and-slot system, requiring no tools or additional hardware.

Get a quote
  • Order custom samples, short runs, or production runs.
  • US-based. Nationwide service.
  • Nationally competitive pricing & delivery costs.
  • Available in a wide variety of configurations.

At a glance

  • Three slanted shelves with front retaining lips
  • Five-piece construction (base, body, 3 shelves)
  • Ships flat and requires a master carton for transit

Get a quote

Share what you know. Exact specifications can follow. Or email us at info@herculeindustrial.com

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for material or strength preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Merchandising Jobs for Slanted Shelves

Gravity-Feed Dispensing

The angled shelves naturally encourage products to slide forward as items are removed. This makes the display an excellent fit for lightweight boxed goods, tubes, or cylindrical items that need to stay front-faced.

High-Visibility Merchandising

For products placed lower to the ground, the downward slant tilts the primary packaging face up toward the shopper's eye line, improving brand visibility compared to deep, flat shelves.

End-Cap Promotions

The tall header and narrow footprint allow this unit to sit at aisle ends, drawing attention to seasonal or promotional merchandise without blocking main store traffic.

Loose or Bagged Item Bins

With the front retaining lip adjusted higher, the slanted shelves can act as shallow bins for loose, bagged, or irregularly shaped items that do not stack neatly on flat surfaces.

Store Rollout and Fulfillment Contexts

Retail Store Rollouts

Because the display ships knocked down in five flat pieces, it minimizes freight volume when distributing to multiple retail locations. Store staff assemble the unit by popping open the pre-glued base, folding the body, and locking the shelves into place.

Kitting and Fulfillment

If the display is being shipped pre-packed with merchandise, fulfillment centers will need to assemble the unit, load the products, and place the entire assembly into a large, protective master shipper or pallet shroud.

Trade Shows and Pop-Up Events

The tool-free, tab-and-slot assembly allows event teams to quickly set up the display on-site and break it down after the event, provided the locking tabs are handled carefully during disassembly.

When to Consider Flat Shelves or Counter Displays

Heavy or Unstable Products

If the products are heavy or prone to tipping over when slanted, a standard flat-shelf floor display may provide better stability and higher weight capacity.

Limited Floor Space

For smaller retail footprints or checkout areas, a corrugated counter display offers similar branding opportunities without requiring aisle space.

Board, Print, and Packing Decisions

Board thickness and side-wall rigidity

The standard B-flute corrugated board is suitable for lightweight items. If the display will hold heavier merchandise, upgrading to a thicker C-flute or double-wall board is necessary to prevent the side walls from splaying or the locking tabs from tearing.

Kitting and master shipper planning

This display is not a shipping container. You must decide whether the five flat components will be kitted together in a single master shipper for store-level assembly, or if they will be shipped in bulk on pallets to a co-packer.

Print routing and graphic placement

Determine which panels require high-graphic printing. The header and base pedestal are primary focal points, while the inside of the body and the underside of the shelves may remain unprinted to manage costs.

Shelf lip height for product retention

The front folded lip on each shelf must be tall enough to stop products from sliding off, but short enough that it does not obscure the primary packaging artwork.

Adjusting Shelf Pitch and Display Proportions

Shelf pitch and vertical clearance

The downward angle of the shelves can be adjusted during the design phase to control how fast products slide forward. The vertical distance between the shelves can also be modified to accommodate taller merchandise.

Header height and base proportions

The top header height can be extended for larger promotional graphics. The base pedestal also provides a continuous surface for branding or instructional artwork.

Side-wall profile and cutouts

The curved profile of the body side walls can be altered to reveal more of the product from the side, provided enough material remains to support the inward-folding shelf tabs.

Packing details

Shelf anchoring and rear tuck tongues

The shelves are supported by tabs that fold inward from the body's side walls. Additionally, each shelf features a back tuck tongue that anchors into the rear panel, preventing the shelf from lifting or walking forward under load.

Additional notes

Shelf angle and product friction testing

For gravity-feed applications, it is critical to prototype the display with your actual product. The friction of your primary packaging will determine if the standard shelf angle needs to be steeper or shallower.

Related Floor and Counter Displays

FAQs

Does this display require glue or tape to assemble?

No. The base is typically pre-glued by the manufacturer and simply pops open. The body and shelves lock together using a mechanical tab-and-slot system, requiring no tools or adhesive at the store level.

How do products stay on the slanted shelves?

Each shelf features a folded front lip. The height of this lip can be adjusted in the template to ensure it securely retains your specific product without obscuring the branding.

Can I ship this display through a parcel network?

Not on its own. The display components must be packed flat inside a corrugated master carton for parcel or freight shipping. If shipping fully assembled and loaded, it requires a heavy-duty outer shipper and internal void fill.

How much weight can the shelves hold?

Weight capacity depends entirely on the chosen board grade and the distribution of the product. Because the shelves are supported by side tabs and a rear anchor, physical load testing with your actual product is strongly recommended before full production.

Can I change the number of shelves?

This specific template is engineered for three shelves. Changing the shelf count requires structural modifications to the body panel's locking holes and overall height.

Where are the best areas for graphics?

The top header is the primary focal point. The base pedestal and the side walls of the main body also offer large, uninterrupted surfaces for high-impact retail printing.

Should I request a physical sample before ordering?

Yes. Because the shelf angle affects how products slide and rest against the front lip, testing a physical prototype with your actual merchandise ensures the pitch and lip height are correct.

Can individual shelves be replaced if damaged?

Because the display consists of five separate pieces, a damaged shelf can technically be swapped out. However, retail displays are typically ordered and shipped as complete kits rather than individual replacement parts.

Ensure your products stand out on the retail floor with a display designed for visibility and easy access.
