EVC62004

Three-Shelf Corrugated Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Six-piece construction ships completely flat
Nested inner and outer body panels lock via inserted shelves
Tab-and-slot base pedestal requires no glue

About this product

This freestanding corrugated display uses a six-piece nested design to create a sturdy, high-visibility retail stand. The base, inner support, outer shell, shelves, and header all ship flat and lock together mechanically, eliminating the need for glued seams.

Because the shelves slide through aligned slots to lock the inner and outer bodies together, this unit offers excellent stability for temporary promotions. However, the multi-part assembly means it is best suited for campaigns where dedicated in-store merchandising or co-packer labor is planned.

Common uses

End-cap promotions
Aisle freestanding displays
Co-packed retail rollouts

Get a quote
