EVC62008

Slanted Shelf Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Slanted shelves for gravity-fed product presentation
Seven-piece kit ships flat and requires manual retail assembly
Tab-and-slot body construction with a separate pop-up base

About this product

This multi-piece corrugated floor display features angled shelves designed for gravity-fed retail presentation. The slanted design naturally pushes products to the front edge, making it useful for magazines, literature, boxed cosmetics, or lightweight packaged snacks.

Delivered as a flat, multi-component kit, the display relies on a precise tab-and-slot system for the main body and a pre-glued crash-lock base for elevation. Because the shelves lock into the side walls using friction, the board thickness must be carefully matched to the product weight and slot dimensions.

Common uses

Magazines and literature
Lightweight boxed goods
Cosmetics
Packaged snacks

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall display width

Overall display depth

Overall display height

Distance between shelves

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What type of products will be displayed?

How many slanted shelves do you need?

Which areas of the display need custom printing?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Applications for Slanted Shelves

Gravity-Fed Product Presentation

The angled shelves ensure that as front items are removed, the remaining inventory slides forward. This reduces the need for store staff to constantly face the display, making it useful for fast-moving lightweight goods.

Literature and Magazine Racks

The tilted profile provides full visibility for the covers of magazines, brochures, or boxed media, allowing customers to browse easily without removing the product from the shelf.

Boxed Cosmetics and Skincare

Uniform, lightweight boxes slide smoothly down the slanted corrugated surface. The gravity feed keeps high-margin items at the front edge for immediate visibility.

Packaged Snacks and Confectionery

For candy bars or bagged snacks that need constant facing, the angled shelves maintain a full appearance even as inventory runs low during a busy retail shift.

Fulfillment and Store-Level Setup

Store-Floor Assembly

This is a seven-piece kit, including the base, rear wall, two side walls, shelves, top shelf, and header. It requires fully manual assembly at the retail location. The base pops open automatically, but the walls and shelves must be carefully slotted together by store staff.

Kitting and Distribution

Because the display consists of multiple large, flat panels, it cannot be shipped through parcel networks as an assembled unit. It must be kitted into a separate corrugated master shipper for safe transit to the retail destination.

Short-Term Promotional Campaigns

Corrugated floor displays offer a temporary retail fixture for seasonal pushes or new product launches. The removable header allows the main structure to remain consistent while branding changes for different campaigns.

When to Consider Flat Shelves or Different Displays

Heavy or Bulky Products

If you are displaying heavy beverages, canned goods, or large hardware, the friction-fit tabs on these slanted shelves may experience too much shear stress. A display with reinforced flat shelves or a different load-bearing structure is usually a safer choice.

Products That Tip Easily

Tall, narrow bottles or top-heavy items may tip forward and fall out of a slanted shelf. If the product cannot slide smoothly or requires a flat resting surface, consider a standard flat-shelf floor display instead.

Key Decisions for Display Configuration

Board Grade and Caliper

The tab-and-slot locking mechanism is highly sensitive to the exact thickness of the corrugated board. Changing from a B-flute to a thicker double-wall board requires recalculating all slot widths to ensure the shelves lock securely without tearing.

Shelf Count and Spacing

The number of shelves and the vertical distance between them should be planned around your exact product dimensions, leaving enough clearance for a customer's hand to easily remove the item.

Print Surface and Branding

Decide which panels require printing. The header, side walls, and base are highly visible, but the inside of the side walls and the rear wall also become visible as products are removed, which may require two-sided printing.

Front Retaining Lip Height

The front edge of each shelf must be tall enough to stop products from falling off the display. Steeper shelf angles or taller products usually require a higher retaining lip.

Adjusting the Display Geometry

Shelf Angle

The tilt angle of the shelves can be adjusted to control how fast products slide forward. Changing this angle alters the side wall profiles and slot positions.

Removable Header

The top header panel slots into the rear wall and is used primarily for branding. It can be resized or shaped to match a specific marketing campaign without altering the main load-bearing structure.

Base Height

The separate crash-lock base acts as a pedestal. Its height can be increased or decreased to bring the bottom shelf to the desired viewing level for retail shoppers.

Packing details

Physical Load Testing

Because the shelves transfer weight through side tabs into the wall slots, physical load testing with the actual product is strongly recommended to verify that the tabs will not shear under the intended weight.

Additional notes

Slot Tolerance and Board Thickness

The structural integrity of this display relies on friction. If the board is thicker or thinner than the slots were designed for, the display will either be impossible to assemble or too loose to hold weight.

FAQs

Does this display require glue or tape to assemble?

The main shelving unit uses a mechanical tab-and-slot system and does not require glue or tape during store setup. The separate base is pre-glued during manufacturing and simply pops open.

How is this display shipped to stores?

It is shipped as a flat kit. All components, including walls, shelves, base, and header, are packed flat into a separate outer master carton for distribution.

Can the angle of the shelves be changed?

Yes, the shelf angle can be adjusted during the design phase. However, changing the angle alters the side wall profiles and may require a taller front lip to keep products secure.

How much weight can the slanted shelves hold?

Weight capacity depends entirely on the chosen board grade and the shear strength of the side tabs. We recommend physical prototype testing with your actual products before committing to a full production run.

Can I use a very thin board to save costs?

Using a thin board may compromise the vertical column strength needed for a tall floor display. The board thickness must provide enough rigidity to support the loaded shelves without the walls bowing.

Are the graphics printed on all pieces?

Print placement depends on your branding needs. The header, side walls, and base are highly visible. The shelves and rear wall can also be printed, which may require specific litho-lamination or digital printing strategies.

Do the shelves need to be glued in place?

No, the shelves use a friction-fit tab-and-slot system that locks into the side and rear walls without adhesive, making store-level assembly entirely mechanical.

Can we print on the inside of the side walls?

Yes, and it is often recommended because the inside panels become highly visible to customers as products are removed from the slanted shelves.
