Retail placements and product fit
High-traffic retail end-caps
The tall profile and top header make this display visible in retail environments. The horizontal shelves are well-suited for presenting multiple product facings.
Beverage and canned goods merchandising
When configured with the heavy-duty variant and double-wall board, the vertical center supports transfer weight directly to the floor, allowing the display to hold heavier items without the shelves bowing.
Stacked boxed goods and multipacks
The flat, rigid shelves provide a stable base for stacking lightweight boxed goods, cosmetics, or packaged snacks.
Temporary promotional campaigns
Because it ships flat and assembles on-site, this display is a practical choice for seasonal product launches or short-term retail promotions.
Distribution and assembly contexts
Direct-to-store retail rollouts
The display ships completely flat, reducing freight volume to distribution centers or individual stores. Store staff or merchandising teams assemble the unit on-site before loading the products.
Pre-packed co-packer programs
For programs where the display is pre-loaded before reaching the store, co-packers can assemble the unit, load the shelves, and ship the entire display inside a protective corrugated master carton.
Trade shows and event merchandising
The knocked-down flat delivery and tab-and-slot assembly make this display easy to transport to events and set up quickly for temporary product presentations.
When to consider alternative displays
Countertop presentations
If floor space is limited or the product is small, a multi-tier counter display may be a better fit than a full-height floor unit.
Pre-packed shipper-displays
If the goal is to ship products inside the display without an outer master carton, consider a tear-away retail-ready shipper instead of an open POP display.
Key display configurations
Shelf count and vertical clearance
Determine how many shelves are needed and the vertical clearance required for your products. Changing the shelf count or spacing will adjust the overall height of the display.
Board grade and payload capacity
The product weight dictates the necessary board strength. Heavier loads may require C-flute or double-wall corrugated, which in turn requires the factory to adjust the slot widths for a proper fit.
Custom header profiles
The top header is a separate piece that slots into the back wall. Its shape can be customized to match brand logos or campaign graphics without altering the main display structure.
Base plinth height and floor clearance
The bottom shelf features a front panel that folds down to the floor, creating a base plinth. This height can be adjusted to raise the lowest products off the ground and protect against shopping cart impacts.
Structural adjustments
Overall footprint scaling
The display width and depth can be scaled to fit specific retail guidelines, such as standard end-cap dimensions or pallet sizes.
Angled or stepped side walls
The top profile of the side walls can be angled or stepped to match branding requirements or provide better visibility to the top shelf.
Shelf front rail depth
The front lip of each shelf folds into a boxed rail. This depth can be adjusted to provide more rigidity or a larger surface for pricing and branding labels.
Packing details
Slot and Tab Clearances
Because this display relies on tabs sliding into slots, the factory must precisely match the slot widths to the physical thickness of the chosen corrugated board. A mismatch will cause the shelves to fit too loosely or tear the side walls during assembly.
Standard versus heavy-duty variants
EVC62011 (Standard Multi-Piece)
The standard design uses a single large body blank with side walls that fold forward. It is a practical choice for standard retail weights.
EVC62011a (Heavy-Duty Glued Body)
This variant uses a three-piece glued body and side walls that fold over 180 degrees. This creates double-thick side walls for higher weight capacity and hides the raw corrugated edges for a premium appearance.
Additional notes
Physical load testing
Always conduct physical load tests with your actual products. While the center supports add structural strength, the final weight capacity depends entirely on the chosen board grade and the distribution of weight across the shelves.
FAQs
How is the display assembled at the store?
The display arrives flat. The main body is folded into a U-shape, the vertical center supports are positioned, and the individual shelves are locked into the side walls using side tabs. The header is then slotted into the top.
How does the display prevent shelves from sagging?
It uses vertical corrugated inserts that run down the center of the display. The shelves intersect with these inserts, transferring the weight from the middle of the shelf directly down to the floor.
Can this display be shipped via parcel networks?
Not on its own. As an open retail display, it offers no transit protection. It must either be shipped flat to the store for assembly, or fully assembled and packed inside a heavy-duty master shipping carton.
Can the top header be a custom shape?
Yes. Because the header is a separate die-cut piece that slots into the main body, its outer profile can be easily customized for specific branding without changing the structural engineering of the shelves.
Why choose the heavy-duty variant?
The heavy-duty variant features side walls that fold over on themselves, creating a double-wall thickness for the shelf slots. This increases the weight the shelves can hold and provides a cleaner look by hiding the raw corrugated edges.
Does changing the corrugated board thickness matter?
Yes, it is critical. The tab-and-slot assembly relies on exact clearances. If you switch from a thinner board to a thicker double-wall board for more strength, the factory must recalculate all slot widths so the pieces still fit together.
Do I need the vertical center support for light products?
For very light products like small cosmetics or snacks, the center support might not be strictly necessary, but it is recommended to maintain the structural shape of the display over time.
Can the inside of the display be printed?
Yes. Since the display is made from flat corrugated blanks, both the inside and outside surfaces can be printed before die-cutting, allowing for full branding across the back wall and side panels.
