Corrugated Multi-Shelf Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Multi-piece construction involves manual tab-and-slot assembly
Slanted shelves feature front barriers to retain product
Ships knocked down flat for co-packer or in-store setup

About this product

This multi-piece corrugated floor display presents products on slanted shelves, angling merchandise upward for better retail visibility. Built with a pedestal base, an angled back profile, and a top header, it serves as a freestanding point-of-purchase destination for lightweight to medium-weight goods.

Because the display is constructed from five separate flat components, including an outer body, an inner slotted tray, individual shelves, front barriers, and a header, it ships efficiently knocked down. This modular method allows for mixed board grades, placing heavier corrugated where support is needed while keeping the shelves lightweight.

Common uses

Point-of-purchase retail end-caps
Trade show product presentations
Co-packed promotional rollouts

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall width

Overall depth

Overall height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How will this display be shipped to retail stores?

About how much weight will each shelf need to hold?

What type of products will sit on the slanted shelves?

Will you need to swap out the top header for different seasonal campaigns?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Rollouts And Promotional Displays

Retail Point-of-Purchase

Useful for end-caps, aisles, or promotional zones where multiple SKUs or high volumes of a single product need dedicated floor space. The slanted shelves improve visibility for lower-tier items, making it easier for consumers to browse.

Co-Packed Promotional Kits

The knocked-down components can be shipped flat to a co-packing facility, assembled, loaded with product, and shipped to retail inside a heavy-duty master carton. This ensures the display arrives at the store ready for immediate placement.

Trade Show Product Presentations

Provides a branded presence for temporary events. The flat-packing design allows event teams to transport the display easily and assemble it on-site without specialized hardware.

Seasonal Aisle End-Caps

Fits well into seasonal merchandising plans where the separate header piece can be swapped out to match different holiday campaigns while keeping the main display body intact.

Merchandising And Co-Packing Environments

Trade Marketing Teams

Provides a large, continuous branding surface on the header, side walls, and pedestal base to command attention in crowded retail aisles. The separate header piece allows for easy graphic updates across different seasonal campaigns.

Fulfillment And Assembly Operations

Needs planning for manual assembly time. The tab-and-slot design avoids glue, but erecting the outer shell, inner tray, and multiple shelves is a multi-step process that dictates the packing rhythm.

Retail Store Managers

Appreciates the organized presentation of slanted shelves, which keep products visible even as inventory runs low. The stable pedestal base helps keep the display from tipping in high-traffic aisles.

When To Consider Simpler Display Styles

Fast In-Store Setup

If retail staff need to set up the display in seconds, a pre-glued pop-up bin or an auto-bottom display may be a better choice than this multi-piece tab-and-slot display.

Heavy Industrial Goods

If the products are exceptionally heavy, such as large beverage bottles or hardware, a reinforced rigid display or a pallet-based stack may be safer than suspended corrugated shelves.

Shelf Count, Angle, And Board Selection

Mixed Board Grades

To optimize material use, the large outer body and inner slotted tray often use a heavier double-wall board for vertical strength, while the smaller individual shelves can use a lighter single-wall board.

Shipping Route

Decide whether the display will ship knocked down directly to stores for staff assembly, or if it will be pre-assembled and loaded by a co-packer. Pre-assembled displays need a dedicated, heavy-duty outer shipping carton to manage the freight network.

Shelf Weight Capacity

Evaluate the total weight of the merchandise per shelf. Heavier items may need thicker board grades or a different flute direction to keep the shelves from bowing over time.

Header Graphic Updates

Determine if the display will be reused for multiple campaigns. The separate header piece can be printed independently, allowing brands to refresh the top messaging without replacing the entire stand.

Adjustments For Product Fit

Shelf Count And Spacing

The number of shelves and the vertical distance between them can be adjusted to match the exact height of the product, ensuring minimal wasted space.

Slant Angle And Tip Stability

The backward tilt of the display can be modified. However, changing this angle shifts the center of gravity, making a physical tip-test highly recommended before full production.

Front Barrier Height

The height of the front barriers can be increased or decreased depending on the product's tendency to slide or roll off the slanted shelves.

Packing details

Caliper-Matched Slots

The slots in the inner tray should exactly match the physical thickness of the corrugated board used for the shelves. Changing board grades means updating the cutting die to avoid loose shelves or torn slots.

Large-Bed Production

The main body and inner tray are large, sprawling blanks that need large-bed flatbed die-cutting. This production method is standard for floor displays but needs specific press capabilities.

Additional notes

Digital cutting for prototypes

Because this display uses multiple large cutting dies for volume production, running a short digital-cut prototype is the best way to verify shelf fit, assembly time, and tip stability before moving to full manufacturing.

FAQs

Does this display require glue to assemble?

No. The display relies entirely on mechanical tab-and-slot connections. The inner tray slides into the folded outer body, and the shelves lock into pre-cut slots.

Can this be set up quickly by retail staff?

This is a multi-piece display that involves folding two large shells, inserting multiple shelves, and attaching barriers and a header. It takes several minutes to assemble and is often better suited for co-packer assembly prior to retail delivery.

How much weight can the slanted shelves hold?

Weight capacity depends entirely on the chosen board grade, flute direction, and shelf width. Physical load testing is strongly recommended to ensure the shelves do not bow under the specific product weight.

Can I ship this display fully assembled?

Yes, but it cannot be shipped bare. A pre-assembled and loaded floor display needs a custom, heavy-duty outer master carton to protect it through the freight or courier network.

Can I print different graphics on the shelves versus the main body?

Yes. Because the body, header, and shelves are cut from separate flat blanks, they can be printed independently, allowing for varied graphic treatments.

Can I change the angle of the shelves?

The overall slant angle of the display can be adjusted, but doing so changes the footprint and center of gravity. Any angle adjustments should be followed by a physical tilt test to ensure the display remains stable in a retail aisle.

Should we test a prototype before full production?

Yes. Because this display relies on precise slot widths and balance, a physical prototype helps verify shelf fit, assembly time, and tip stability before committing to a large run.

What keeps products from sliding off the slanted shelves?

The display includes separate front barrier pieces that attach to the front edge of each shelf, creating a lip that retains the merchandise.
