EVC62050

Two-Sided 4-Shelf Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Two-sided visibility with 8 total shelves
Rigid interlocking chassis with a protective base plinth
Delivered flat as a multi-component kit

About this product

The EVC62050 is a freestanding corrugated floor display designed for wide retail aisles and open spaces. It features a central dividing spine and angled side walls that create a rigid, tapered chassis, supporting four shelves on the front and four on the back.

Because it presents products in two directions, it is an excellent choice for high-traffic end-caps and promotional zones. The display is delivered as a multi-piece flat kit, requiring manual assembly at the retail store or fulfillment center.

Common uses

Snack and confectionery end-caps
Cosmetics and health/beauty aisle displays
Lightweight boxed goods promotions

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall width

Overall depth

Overall height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What is the estimated weight of the products on each shelf?

How will the displays be shipped to retail stores?

Which areas of the display require custom printing?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Placements for Two-Sided Displays

Wide-aisle retail promotions

The dual-face design maximizes product exposure in open retail environments where shoppers approach from multiple directions. It is well suited for snacks, cosmetics, and lightweight boxed goods.

End-cap product launches

When positioned at the end of a gondola run, the two-sided structure allows high-volume presentation of a single campaign facing both the main aisle and the cross aisle.

Seasonal and holiday campaigns

The large branding surfaces and high product capacity make this display useful for short-term seasonal pushes where floor space is temporarily allocated for special items.

Cross-merchandising setups

The divided nature of the display allows brands to present complementary products on opposite sides, such as chips on the front shelves and dips on the back shelves.

Fulfillment and Store-Level Assembly

Store-level assembly and setup

This display relies on mechanical tab-and-slot interlocking rather than glue. Because it involves over 15 separate pieces, including the chassis, shelves, barriers, and header, clear printed assembly instructions should be included in the kit to ensure store staff build it correctly.

Fulfillment and kitting centers

The flat components must be collated and packed into a single master shipper. The sheer size of the central divider and side panels usually dictates they are cut on separate sheets from the smaller shelves and barriers.

Brand managers planning multi-store rollouts

For national campaigns, the separate header card allows the main chassis to remain consistent while the top branding is swapped out for different retailers or seasonal phases.

When to Consider Single-Sided or Different Shelf Counts

Wall-facing or inline retail placements

If the display will be pushed against a wall or integrated into an existing retail shelf run, a single-sided display uses less floor space and requires fewer components.

Heavy beverage or bulk liquid displays

Corrugated shelves without front-to-back reinforcement tubes may sag under heavy point loads. If packing heavy bottles or cans, a different structural style with reinforced shelving is usually required.

Board Choice and Kitting Strategy

Board thickness for chassis versus shelves

To balance strength and cost, these displays often use a mixed-caliper approach. The load-bearing central divider and side walls may require a sturdy double-wall board, while the shelves, front barriers, and header can use a lighter single-wall board. The template must be adjusted for these specific thicknesses so the interlocking slots fit perfectly.

Two-sided print and branding coverage

The angled side panels, the top header, and the shelf barriers are the primary branding surfaces. Decide whether the central divider requires printing, as it is partially visible between the products.

Master shipper and kitting plans

Because the display consists of many flat parts, the dimensions of the largest piece will dictate the size of the outer shipping box. Planning the collation order helps fulfillment centers pack the kits efficiently.

Vertical clearance for taller products

The vertical distance between shelves must be finalized before production. Adjusting this clearance to accommodate taller products will alter the overall height and angle of the side walls.

Customizing the Header and Shelves

Custom header profiles

The top header is a separate inserted card. Its top profile can be die-cut into custom shapes to match campaign branding, provided the bottom interlocking tabs remain unchanged.

Adjustable shelf spacing

The vertical distance between shelves can be adjusted during the design phase to accommodate taller products, which will alter the overall height and angle of the side walls.

Base tray and foot elevation

The display sits on a separate folded foot and tray assembly. This elevates the bottom shelves, protecting the main chassis from floor moisture and shopping cart bumps.

Packing details

Base plinth protection

The display sits on a separate folded foot and tray assembly. This elevates the bottom shelves, protecting the main chassis from floor moisture and shopping cart bumps.

Additional notes

In-store tape and glue reinforcement

While the display uses mechanical tab-and-slot joints, heavy retail environments may prompt store staff to use clear tape or hot melt glue during setup for extra rigidity.

FAQs

How is this display assembled in the store?

It is a multi-piece kit that requires two-handed manual assembly. The base is folded first, followed by interlocking the central spine and side walls to form the chassis. The shelves and barriers are then slid into place. Clear instructions are highly recommended.

Can this display hold heavy items like beverages?

Corrugated shelves without front-to-back reinforcement tubes may sag under heavy point loads. It is best suited for lightweight to medium-weight goods. Any heavy application requires physical testing with a heavy-duty board grade.

How is the display shipped to the store?

All components (divider, side walls, shelves, base, and header) are die-cut and delivered flat. They must be collated and packed into a separate, robust outer corrugated shipper for transit.

Does the whole display need to be made from the same board thickness?

No. The design supports mixed-caliper kits. A common approach uses a strong double-wall board for the vertical chassis and a lighter single-wall board for the shelves and header. The factory will adjust the slot widths to match the chosen materials.

Which parts of the display are usually printed?

The top header, the angled side walls, and the front shelf barriers offer the most visible branding space. The central divider can also be printed if it will be visible behind the products.

Can I change the number of shelves?

Changing the shelf count alters the entire interlocking slot grid on the central spine and side walls. If you need a different number of shelves, it is usually better to start with a template specifically designed for that count.

Do the shelves have a front lip to keep products in place?

Yes, the design includes separate barrier strips that attach to the front edge of each shelf, creating a retaining lip to prevent products from sliding off.

Should we test a prototype before ordering a full run?

Yes, testing a physical prototype is highly recommended to verify that the interlocking slots fit the chosen board thickness, to check the assembly time, and to ensure the shelves support your specific product weight.
