EVC62061

Two-Sided Corrugated Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Dual-sided product access for open aisles
Interlocking tab-and-slot shelves
Ships flat as a multi-component kit

About this product

This freestanding, multi-shelf floor display is designed with an open back, allowing shoppers to view and access products from both sides. It is built for center-aisle retail placements where 360-degree visibility is a priority.

The display relies on two vertical pillars and a cross-braced base, allowing it to stand without a solid back wall. Shelves lock into the pillars using a tab-and-slot mechanism, and the entire multi-piece kit ships flat for on-site assembly.

Common uses

Center-aisle promotions
Open-floor seasonal displays
Dual-branded product launches

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall display height

Shelf width

Shelf depth

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How many shelves do you need?

How will the display be printed?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Placements for Dual-Sided Displays

Center-aisle retail promotions

The open-back design provides product exposure in wide retail aisles where foot traffic flows in multiple directions.

Freestanding open-floor displays

A wide, cross-braced base skirt provides a foundation without relying on a wall or gondola for support.

Dual-branded product launches

The two-sided architecture allows two different brands or product lines to share the same physical footprint while facing opposite directions.

Seasonal merchandise rollouts

Ships flat to retail locations, allowing store staff to assemble the display and load seasonal inventory directly on the floor.

Merchandising and Promotional Programs

High-traffic retail environments

Open-back access allows shoppers to pick products from either side.

Store-level assembly programs

The multi-part kit is designed for manual assembly by retail staff without specialized tools.

Mixed-product merchandising

Adjustable shelf heights accommodate different product sizes on the same display unit.

When to Consider a Single-Sided Display

Wall or end-cap placements

If the display will be pushed against a wall or gondola end, the rear access is wasted. A single-sided display with a solid back wall changes the lateral balance and provides a larger rear graphic panel.

Heavy palletized shipping

If the display needs to ship fully loaded with heavy goods, a pre-packed shipper with an outer corrugated shroud may be a better choice than a flat-packed kit assembled on-site.

Board Selection and Kitting Strategy

Mixed board grades for frame and shelves

The vertical pillars and internal base supports often use heavier fluting to carry weight, while the shelves can use a thinner profile for print quality and easier folding.

Kitting and flat-pack bundling

Because the display consists of multiple separate components, the flat blanks must be bundled and kitted logically for the end user.

Shelf load testing

The tab-and-slot connection is the primary load-bearing point and should be validated with the actual product weight before full production.

Print surface and graphic alignment

The header cap and base skirt are highly visible from both sides, requiring careful artwork alignment for two-sided printing.

Modifying Shelves and Clearances

Shelf count and vertical clearance

The number of shelves and the vertical distance between them can be adjusted to fit specific product heights.

Base skirt height and floor clearance

The angled base can be raised to elevate the bottom shelf further off the floor, keeping products away from floor-level activity.

Header cap dimensions

The top header can be sized to accommodate different promotional graphics or die-cut shapes.

Packing details

Internal base supports and floor weight transfer

The visible base skirt hides a set of interlocking corrugated supports that transfer vertical weight directly to the floor.

Additional notes

Board thickness and shelf slot clearance

If you change the board grade of the shelves, the receiving slots on the vertical pillars must be recalculated to ensure the tabs fit the slots correctly.

Header cap and lateral stability

Without a back wall, the header cap and the base skirt are critical for keeping the display square. Ensure these components are fully seated during assembly.

Kitting and bundle size

The multiple components of this display must be bundled together. Consider the final weight and dimensions of the flat kit for retail staff handling.

FAQs

How much weight can the shelves hold?

Load capacity depends on the chosen board grade and physical testing. The tab-and-slot connection is the primary load-bearing point and should be validated with your actual product.

How is this display assembled at the store?

The vertical pillars are usually pre-glued into tubes by the converter. Store staff fold the base, insert the cross-braces, slide the folded shelves into the pillar slots, and cap it with the header.

Can the header be printed on both sides?

Because the display is shopped from two directions, the header cap is highly visible from both the front and the back, allowing for dual-sided printing.

Does this require an outer shipping box?

If shipping through parcel or LTL networks, the flat-packed kit is usually placed in an outer corrugated shipper to cover the edges before assembly.

Can the shelves be adjusted after assembly?

The shelf positions are fixed by the slots cut into the vertical pillars during manufacturing. If you need adjustable heights, the slot pattern must be designed into the pillars upfront.

What board grades are typically used?

It is common to mix board grades. The load-bearing pillars and base supports often use a heavier C-flute or BC-flute, while the shelves and header might use a thinner B-flute or E-flute for better print quality.

How does the display stay upright without a back wall?

The display relies on the wide, cross-braced base skirt and the top header cap to keep the vertical pillars square and upright.

Can this display be shipped fully loaded with product?

This display is generally designed to ship flat and be assembled and loaded at the retail store. Shipping it fully assembled and loaded would require a heavy outer corrugated shroud and careful palletization.
