EVC62130

Corrugated Cell Floor Display with Curved Roof

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Multi-piece interlocking grid for individual product sorting
Ships flat (KD) to reduce transit volume before assembly
Pre-cut holes support optional display clips or bolts for added stability

About this product

The EVC62130 is a freestanding corrugated retail display designed to organize and present multiple products in distinct, individual compartments. Featuring an interlocking egg-crate grid of shelves and dividers, it creates a highly structured presentation that ships completely flat.

Because it relies on multiple interlocking components and optional mechanical fasteners, this display requires planned manual assembly. It is an excellent choice for multi-SKU rollouts where organized visual merchandising outweighs the labor of store-level or co-packer setup.

Common uses

Multi-SKU cosmetic or hardware rollouts
Toy or novelty sorting
Seasonal retail promotions

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Number of columns

Number of rows

Target compartment size

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

Do you want to keep the curved roof panel?

How should this display be printed?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Merchandising and Product Sorting

Multi-SKU product launches

The individual compartments keep diverse product lines, flavors, or variations neatly separated. This prevents retail shelves from becoming disorganized over time, making it a strong fit for cosmetics, hardware, toys, or novelty items.

High-visibility endcap or aisle placement

With its distinct curved roof and structured grid, the display acts as a standalone fixture. It draws attention in open floor spaces where standard shelving is unavailable.

Seasonal and promotional assortments

For holiday gift sets or limited-edition releases, the individual cubbies provide a dedicated space for each variant, ensuring the presentation remains neat even as shoppers remove items.

Retail floor sorting for small loose items

When merchandising craft supplies, small hardware parts, or novelty goods, the egg-crate grid prevents items from mixing, reducing the need for separate inner cartons.

Rollouts, Co-Packing, and Store-Level Setup

Co-packer assembly programs

Because the display requires aligning multiple slotted dividers and shelves, many buyers route these to a co-packer. The co-packer builds the grid, loads the product, and ships the fully stocked display on a pallet to the retail distribution center.

Store-level flat delivery

For programs where retail staff handle setup, the display's flat components can be kitted into a single master shipper. Clear instructions are necessary, as the interlocking egg-crate mechanism requires careful alignment before the outer walls and roof are attached.

Trade show and event merchandising

Brands exhibiting at trade shows can ship the flat components directly to the venue. The manual tab-and-slot assembly allows staff to build a large, organized presentation without requiring tools or adhesives.

When to Consider Simpler Display Formats

Fast-setup retail requirements

If retail staff have limited time for assembly, a multi-piece interlocking grid may be too complex. Consider a pop-up display or a pre-glued tiered floor display that opens in a single motion.

Heavy or oversized products

While the vertical dividers provide excellent top-to-bottom strength, the horizontal shelves rely on the board's rigidity across the span of each cell. For heavy liquids or dense goods, a display with reinforced metal shelving or a different structural base should be evaluated.

Board, Fasteners, and Assembly Planning

Board caliper and slot tolerances

The stability of the entire display depends on friction. The width of every slot in the dividers and shelves must exactly match the physical thickness of the chosen corrugated board. Changing from a B-flute to a double-wall board requires recalculating every intersecting cut.

Mechanical fasteners

The outer walls feature pre-cut holes designed to align with the internal grid. You will need to decide whether to use plastic display clips, bolts, or rely entirely on the friction fit of the tabs and slots to keep the display locked together.

Print and graphic treatment

Because both the inside and outside of the cells are visible to the consumer, the board often requires double-sided printing or litho-lamination. The curved roof also provides a prominent, continuous billboard for brand messaging.

Shelf weight testing

Before finalizing the board grade, evaluate the density of the products being loaded. The horizontal shelves should be physically tested with the exact product to ensure they do not sag over the span of the cell.

Configuring the Cell Grid and Roof

Cell count and dimensions

The number of columns and rows can be adjusted to fit the exact product assortment. Changing the cell count automatically updates the number of required vertical dividers and horizontal shelves.

Roof profile modifications

The curved roof panel is primarily aesthetic. Its height and overhang can be modified, or it can be removed entirely if an open-top grid is preferred for the retail environment.

Fastener hole placement

The number and spacing of the pre-cut holes along the outer walls can be adjusted to match the specific plastic clips or bolts planned for the final retail assembly.

Packing details

Master shipper requirements

This display is a presentation fixture, not a shipping container. The flat components must be packed inside a separate corrugated master shipper to protect the tabs, slots, and printed surfaces during transit to the assembly location.

Additional notes

Board thickness and slot friction

Because the grid relies on intersecting slots, the CAD file must be perfectly matched to the actual thickness of the corrugated board. Even minor variations in board caliper can cause the display to fit too loosely or tear during assembly.

FAQs

Can this display be assembled automatically?

No. The display consists of at least nine distinct flat components that must be manually slotted together in a specific sequence. It is not compatible with automated folder-gluers or case erectors.

How much weight can the individual cells hold?

Weight capacity depends entirely on the chosen board grade and the width of the cell. While the vertical dividers provide strong overall compression resistance, the horizontal shelves should be physically tested with your exact product to ensure they do not sag.

Which surfaces of the display are visible to the customer?

Almost all surfaces are visible. The exterior walls, the curved roof, and both the top and bottom of the internal shelves and dividers can be seen. Double-sided printing is usually required for a fully branded appearance.

Can the assembled display be shipped via parcel networks?

No. Once assembled, the display is a rigid retail fixture. It must either be shipped flat in a master carton for store-level assembly, or built and shipped on a protected pallet by a co-packer.

Are glue or tape required to build the display?

The primary structure relies on interlocking slots and tabs. However, the outer walls include pre-cut holes designed for plastic display clips or bolts to securely lock the panels in place without adhesive.

Can the size of the cubbies be changed?

Yes. The width, depth, and height of the individual cells can be adjusted to match your product. The template will automatically recalculate the necessary slot spacing and overall display footprint.

What keeps the curved roof attached to the grid?

The roof panel features slots that drop into corresponding tabs on the top edges of the vertical dividers and the rear wall, locking the top span together.

How is the display protected if shipped flat to stores?

Because the display consists of multiple flat panels with exposed tabs and slots, it requires a separate corrugated master shipper to protect the components and printed surfaces during transit.
