360-degree open access for retail floor placement
Vertical load carried by internal interlocking divider grid
Delivered flat; requires manual multi-component assembly

About this product

The EVC62133 is a multi-tier corrugated floor display designed for 360-degree retail access. Instead of relying on outer walls for support, it uses a central grid of thick, interlocking dividers to carry the vertical load, allowing the sides to remain open for product visibility.

Because it is built from modular trays, dividers, and a top header cap, this display requires manual assembly at the fulfillment center. It is a practical fit for lightweight, compartmentalized merchandise placed in open floor spaces or end-caps.

Common uses

Retail end-caps
Open floor merchandising
Sorted lightweight product presentation

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Individual cell width

Individual cell depth

Overall display height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What type of products will be displayed?

How will the loaded display travel to retail stores?

Who will assemble and load the display?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail Floor and End-Cap Merchandising

Open-Floor Retail Presentation

The open-sided design allows shoppers to approach and select products from any direction. This makes it effective for center-aisle placements, end-caps, and promotional zones where standard one-sided shelving would block traffic flow or limit visibility.

Sorted Lightweight Merchandise

The individual cells naturally separate mixed product lines, flavors, or colors. It is a strong fit for lightweight packaged goods, snacks, or small retail items that benefit from compartmentalized presentation without requiring heavy-duty structural support.

End-Cap and Aisle Intersections

When placed at the end of an aisle, the multi-sided access ensures products are visible to cross-traffic. The compartmentalized design keeps smaller items organized even when shopped heavily.

Seasonal and Promotional Campaigns

For temporary retail events, this modular display provides a large volume of sorted product space. The header cap and tray walls offer dedicated surfaces for campaign branding.

Fulfillment and Co-Packing Realities

Co-Packing and Assembly Labor

This is a multi-piece structure. The converter glues the dividers into flat tubes, but the co-packer must open them, interlock the grid, fold the tray walls, and stack the tiers. Buyers must budget for this manual assembly time before loading the product.

Retail Distribution

Once assembled and loaded, the display requires a dedicated corrugated outer shipper or pallet shroud to protect the open cells and maintain tier stability during transit to the retail store.

Store-Level Setup and Placement

Because the display arrives at the store fully loaded inside a master carton, retail staff only need to remove the outer shroud and place the unit on the floor. The interlocking grid keeps the tiers stable during this final placement.

When to Compare Rigid Bins or Pop-Up Displays

Heavy or Bulky Products

If the product is heavy, the internal corrugated dividers might crush or bow under the stacked weight. For heavy goods, compare this with rigid stackable bins or displays that transfer weight through reinforced outer walls.

High-Speed Fulfillment

If the packing line requires rapid, pop-up assembly, this multi-component display will slow down operations. Consider a simpler, single-piece pop-up display or a pre-glued auto-bottom structure.

Tier Count, Board Grade, and Transit Shrouds

Tier and Cell Count

The number of vertical tiers and the grid layout dictate the overall height and footprint. Taller displays require stiffer board grades for the bottom dividers to prevent crushing under the combined weight of the upper tiers.

Board Grade and Flute Direction

The internal dividers do the heavy lifting. The flute direction on these dividers must run vertically to provide column strength. The board grade must be specified based on the total loaded weight of the display.

Outer Shipper and Transit Protection

Because the cells are open, the loaded display needs a master carton or corrugated shroud for distribution. This outer packaging must be planned alongside the display itself to ensure a proper fit.

Print Surfaces and Branding

Decide whether the inside of the tray walls or the internal dividers need printing. While the header cap is the primary branding surface, the open design makes the interior visible to shoppers.

Cell Dimensions and Header Branding

Cell Dimensions

The width, depth, and height of the individual compartments can be adjusted to fit specific product sizes, which automatically recalculates the overall tray footprint and divider lengths.

Header Cap Branding

The top header caps the display and provides a primary surface for branding. Its height and side-wall angles can be modified to accommodate different graphic requirements.

Tray Wall Angles

The angle of the outer tray walls can be adjusted. A steeper angle provides deeper product retention, while a shallower angle increases product visibility and access.

Packing details

Tray Locking Mechanism

The outer tray walls do not require tape or glue during final assembly. They fold up 90 degrees and secure to the internal divider grid using integrated tuck tongues that seat into corresponding lock holes.

Additional notes

Outer transit shrouds for open cells

Because the cells are open on all sides, the loaded display is vulnerable to dust and lateral impacts during transit. A full corrugated outer shroud is necessary for distribution to retail stores.

FAQs

Does this display require glue or tape to assemble?

The manufacturer glues the internal dividers into flat tubes before delivery. The final assembly at the co-packer relies entirely on mechanical locks, such as tuck tongues and slots, without needing additional tape or glue.

How is the vertical weight supported?

The weight is carried by the internal grid of dividers, not the outer tray walls. Each tray rests directly on the thick, folded dividers of the tier below it.

Can this display be shipped fully assembled?

It can be shipped assembled to retail stores only if it is enclosed in a rigid corrugated master shipper or pallet shroud. It is not suited for mixed-carrier parcel networks in its assembled state due to the open cells and stacked tiers.

Is this suitable for heavy items like beverages or hardware?

Generally, no. While the thick dividers provide good column strength, the multi-tier stacked design is meant for lightweight to medium-weight retail merchandise. Heavy items increase the risk of the bottom dividers crushing.

Where does printing usually go on this display?

The top header cap is the primary branding surface. The outer tray walls and the visible portions of the internal dividers can also be printed, though two-sided printing may be required depending on how the dividers fold.

Can the number of tiers be changed?

Yes. The template allows for adjusting the number of vertical tiers. However, adding tiers raises the center of gravity and increases the load on the bottom dividers, which must be validated with physical testing.

Can the tray walls be printed on both sides?

Yes, if the design requires branding on the inside of the tray walls, two-sided printing can be specified. This is often useful since the open design makes the interior visible to shoppers.

How are the internal dividers delivered?

The manufacturer glues the dividers into flat tubes. The assembly team then opens these tubes and slots them together to form the load-bearing grid.
