Two-Step Corrugated Floor Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Five-piece modular construction
Stepped tray with internal product cells
Ships flat for retail assembly

About this product

The EVC62231 is a five-piece corrugated floor stand designed for point-of-purchase retail environments. It features a tall base pedestal, a stepped product tray, an internal divider, a top shelf, and a rear header panel for branding.

Because it relies entirely on mechanical tab-and-slot connections, it ships flat as a multi-component kit and is assembled manually on the store floor. It is a practical choice for presenting loose or boxed goods in distinct compartments.
