Modular Corrugated Cell Wall Display

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Modular grid built from individual locking cubbies
Thick hollow frames create a substantial appearance
Relies on hand assembly at the retail or event location

About this product

The EVC62820 is a modular corrugated display system that builds freestanding, multi-compartment shelving or partition walls. It uses individual open-faced cubbies with thick, hollow perimeter frames that stack and lock together into a rigid grid.

Because each cell is folded individually and joined with separate locking pieces, this display involves hand assembly. It trades fulfillment labor for a substantial presentation on the retail floor.
