EVC62861

Modular Hexagonal Display Wall

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Builds into custom freestanding honeycomb configurations
Thick double-wall frames create a premium, chunky aesthetic
Requires manual folding and stacking at the retail location

About this product

This modular display system builds into a striking, freestanding honeycomb wall. Each hexagonal cell features inward-folding front and back edges that create a thick, premium frame, elevating the presentation beyond standard corrugated shelving.

Because the system relies on individual cells, flat base units, and slotted locking clips, it offers complete flexibility for retail footprints. However, this high visual impact requires dedicated manual assembly at the store or event level.

Common uses

Pop-up shops requiring temporary but premium-looking fixtures
Trade show walls and exhibition backdrops
Lightweight apparel, cosmetic, or packaged goods retail displays

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Single cubby width

Cubby depth

Target wall dimensions

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

Who will be assembling the display wall?

What type of items will be placed inside the cubbies?

Where will this display mainly be used?

How do you plan to print the display?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail and Exhibition Display Applications

Freestanding retail shelving

The specialized base units provide a stable, flat footprint, allowing the stacked hexagonal cells to act as lightweight shelving for apparel, cosmetics, or packaged goods. The thick folded frames hide raw corrugated edges, giving the display a finished, fixture-like appearance.

Trade show and event walls

Because the entire system ships flat, it is very efficient to transport to events. Teams can assemble the cells on-site and lock them together to create custom backdrops or product presentations that command attention.

Pop-up shop merchandising

Temporary retail spaces often need premium aesthetics without the commitment of permanent wood or metal fixtures. The honeycomb wall provides a custom architectural element that can be broken down and recycled after the event.

Lightweight product presentations

The individual cubbies naturally frame smaller items like folded apparel, boxed cosmetics, or specialty foods. The thick front edges draw the eye inward, creating a focused presentation for each product.

Pop-Up Shops and Temporary Retail

Visual merchandising teams

Merchandisers can configure the wall height and width by adding or removing cells. The modular nature allows the same base components to be reused in different store layouts or seasonal campaigns, adapting to the available floor space.

Event and exhibition planners

For trade shows, the ability to ship a large architectural wall completely flat reduces freight volume. The modular cells can be arranged to fit specific booth dimensions or create freestanding partitions.

Temporary retail operators

Pop-up stores benefit from the balance of high visual impact and temporary materials. The corrugated structure provides a finished look that elevates the brand presence for short-term leases.

When to Consider Simpler Floor Displays

High-volume, fast-setup retail rollouts

If store staff have very limited time for assembly, a multi-cell wall may be too labor-intensive. A pre-glued pop-up floor display or a standard tiered dump bin will deploy much faster, though with a more conventional look.

Heavy-duty load bearing

While the honeycomb structure provides good vertical stability, the individual cells rely on folded corrugated board and tuck tongues. If the display must hold heavy beverages or large hardware, a standard tiered display with reinforced shelves is worth evaluating.

Print Layout and Board Thickness Planning

Board grade and lock clip tolerances

The U-shaped locking clips that bind the cells together must exactly match the crushed thickness of the corrugated board. Changing from a standard B-flute to a thicker C-flute requires adjusting the slot width to ensure the wall remains stable without tearing the clips.

Print mapping for inward-folding frames

The panels that line the inside of each cell actually fold inward from the outer perimeter of the flat blank. Artwork must be mapped carefully so that the correct graphics face outward once the thick front and back frames are locked into place.

Cell depth and product fit

The depth of the hexagonal tube determines how far products sit inside the cubby. This dimension should be checked against the product size to ensure items do not overhang the front edge or get lost in the back.

Base stability and wall height

The ratio of base units to stacked cells determines the overall stability of the wall. Tall or top-heavy configurations should be evaluated for tipping risk, especially in high-traffic retail aisles.

Modifying Cell Depth and Wall Scale

Cell depth and diameter scaling

The depth of the cubbies and the overall diameter of the hexagons can be scaled to fit specific products. However, very large cells will require oversized flatbed die-cutting, which can limit production to specialized equipment.

Frame thickness adjustments

The width of the inward-folding trapezoidal flaps determines the thickness of the front and back frames. This can be adjusted for a chunkier or slimmer aesthetic, though it alters the overall blank proportions.

Tuck tongue retention

The locking tabs that secure the inner walls can be resized. Ensuring these tabs are large enough to hold the board tension is critical for keeping the frame folded during retail use.

Packing details

Nesting lock clips to reduce waste

The small locking clips can often be nested into the waste areas between the angled flaps of the main cell blanks. This efficient layout helps reduce overall material usage during die-cutting.

Additional notes

Base unit stability and tipping risk

The specialized base cells feature an extended floor panel to provide a flat footprint. Even with these bases, tall or top-heavy configurations should be evaluated for tipping risk, especially in high-traffic retail aisles.

FAQs

How are the individual cells connected?

Once the hexagonal tubes are popped open and the front and back frames are folded inward, the cells are stacked. Small, U-shaped corrugated clips are then pushed into aligned slits on the outer walls to lock the adjacent cells together.

Does this display require tape or glue for assembly?

The main side seam of each cell is glued during manufacturing. Store-level assembly relies entirely on mechanical folds, tuck tongues, and the locking clips. No tape or additional adhesive is needed on-site.

Can this honeycomb wall hold heavy products?

While the honeycomb structure provides good vertical stability, the weight capacity of each individual cell depends heavily on the board grade and the retention of the tuck tongues. Heavy items like beverages or large hardware should be physically tested before a full rollout.

Are the inside walls of the cells printable?

Yes. The inner walls are formed by panels that fold inward from the main blank. This means the interior lining and the exterior walls are printed on the same side of the corrugated sheet, simplifying the printing process.

How does the display ship to stores?

The cells, base units, and locking clips are delivered flat (knocked down). This makes the system very space-efficient for transit, though it shifts the assembly burden to the final destination.

Is this structure suitable for short promotional runs?

Yes, if cut digitally. For larger runs, the complex flaps and large blank size require flatbed die-cutting. Digital cutting tables fit short runs, prototypes, or event-specific walls where a trial run is preferred.

How do the base units differ from the standard cells?

The base units are identical to the standard cells but include an extended rectangular floor panel. This flat footprint prevents the hexagonal wall from rolling or tipping forward.

Can the wall be reconfigured after initial assembly?

Yes. Because the cells are connected with removable corrugated clips rather than glue, the wall can be disassembled and restacked into different shapes for future events or changing floor plans.
