ECMA F20.60.00.00

Pre-Glued Downfold Tray with Attached Lid

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Fast manual setup via pre-glued corner webs
Double-thick walls mimic a premium rigid box
Stores flat (KDF) to save warehouse space

About this product

This one-piece, flat-folding clamshell box delivers the double-wall aesthetic of a rigid setup box without the massive warehouse footprint. Delivered flat, it features pre-glued diagonal corner webs that allow the base and lid to snap into shape when the walls are pulled upward.

Because it relies on 4-corner gluing during production, it is often chosen for larger retail, apparel, and bakery programs where fast manual packing and high-end presentation are the top priorities.

Common uses

Boutique apparel
Premium bakery and confectionery
Gift kitting
Cosmetics presentation

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Inside length

Inside width

Inside depth

Size notes

Quantity notes

Materials and print

Paperboard preference

Add details for paperboard preference

Paperboard details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How will this box be shipped to the final customer?

What type of items will go inside?

Will you need a custom insert to hold items in place?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Premium Retail and Presentation Fits

Boutique Apparel and Accessories

The clean, double-wall interior and attached hinged lid create a high-end unboxing experience for shirts, scarves, and leather goods. The fast snap-up assembly keeps store-floor or fulfillment-center labor costs low.

Premium Bakery and Confectionery

Often used for pastries, chocolates, or specialty foods where a hinged lid and rigid feel are expected. The flat-folding nature allows bakeries to keep large quantities on hand without sacrificing back-room space.

Gift Kitting and Cosmetics

Provides a sturdy, attractive base for inserts and product assortments. The friction-fit lid closes smoothly over the base, offering a clean canvas for foil stamping or embossing.

Corporate Onboarding Kits

Delivers a presentation-ready unboxing moment for employee welcome kits or promotional items, while remaining easy to store flat until the kits are assembled.

Who Gets the Most Value Here

Fast-Paced Manual Fulfillment

If your packing line relies on manual labor, this box eliminates the slow folding and locking steps of standard roll-end trays. The operator simply pulls the walls up, loads the product, and closes the lid.

Space-Constrained Retailers

True rigid setup boxes ship empty, eating up pallets and storage rooms. This design gives you a similar presentation but arrives knocked-down flat, reducing freight and storage overhead.

Premium E-Commerce Programs

When paired with a corrugated outer shipper, this carton provides the high-end interior presentation that e-commerce brands want, without the cost of shipping fully erected rigid boxes to the fulfillment center.

When to Consider a Different Box Style

When you need a standalone shipping box

This box relies on a friction-fit lid and is designed for retail presentation or inner kitting. If it will travel through a parcel network, it usually needs an outer corrugated shipper or strong tamper seals.

When running very short or digital trials

The 4-corner pre-gluing relies on specific folder-gluer machine setup. For very short runs, an unglued roll-end tuck-top may be more practical to avoid machine setup time, trading slightly slower manual assembly for lower upfront production barriers.

Key Decisions for Production and Route

Board Grade and Crack Resistance

Because the production process folds the board 180 degrees to create the double walls and glued webs, the package relies on a high-quality, crack-resistant board like SBS or FBB. Lower-grade recycled boards or corrugated micro-flutes may crack or bind during these tight folds.

Lid Clearance and Friction Fit

The lid is designed to telescope over the base walls. The exact thickness of your chosen board changes how much clearance is needed. The layer step creases are adjusted to ensure the lid closes smoothly without bowing the base walls or popping open.

Outer Shipping Strategy

If the box will be mailed directly to consumers, decide early if you will use a clear wafer seal, a branded sleeve, or a separate corrugated outer box to keep the friction-fit lid closed during transit.

Print and Finish Placement

The outer panels offer a smooth surface for premium finishes, but foil stamping or heavy varnishes should be kept away from the diagonal corner webs where the converter applies adhesive.

Structural Adjustments and Clearances

Lid Tapers and Extensions

The inner walls of the lid can be tapered slightly to prevent them from catching on the base walls during closure. The lid panel extensions can also be adjusted to loosen or tighten the friction fit based on your product's weight and handling needs.

Layer Step Crease Calibration

The creases that form the double walls are offset based on the exact caliper of the board. This ensures the carton folds completely flat for shipping without binding or tearing the hinge.

Base and Lid Height Ratios

While the lid often telescopes fully over the base, the heights can be adjusted so the lid only partially covers the base walls, creating a different visual profile when closed.

Board and packing details

Grain Direction for Hinge Durability

To prevent the main rear hinge from cracking after repeated opening and closing, the board's grain direction should run parallel to the hinge line. This is especially important for keepsake boxes intended for long-term use.

Variants

F20.60.00.00.a (Adjusted Lid Clearance)

A variant that introduces specific mathematical clearances and tapers to the lid panels, ensuring a smoother telescoping fit over the base when using thicker board grades.

Additional notes

Print surface and finishing

Because the outer panels are fully exposed and the board is typically a smooth, high-grade cartonboard, this style is an excellent candidate for premium finishes like foil stamping, embossing, and spot UV.

FAQs

Comparison

Is this the same as a rigid setup box?

No. A true rigid setup box is made of thick chipboard wrapped in paper and cannot be folded flat. This is a folding carton designed to mimic that premium double-wall look while still shipping and storing completely flat.

Shipping & Route

Can I ship this box through the mail as-is?

It is not recommended. The hinged lid relies on a friction fit and can easily open during rough courier handling. For parcel shipping, it should be placed inside a corrugated mailer or secured with strong outer tape or shrink wrap.

Production & Quantity

Why is this style often chosen for larger order volumes?

The box is typically run on a multi-point folder-gluer to apply adhesive to four separate corner webs (two on the base, two on the lid) in a single pass. This machine setup makes it efficient at scale, but less practical for very small runs.

Materials

Can this be made from corrugated board?

Usually not. The design relies on the material folding 180 degrees flat against itself to form the double walls and glued webs. Corrugated flutes tend to crush, bind, or crack under these tight tolerances. It performs well with high-quality solid bleached sulfate (SBS) or folding boxboard (FBB).

Packing Labor

How much faster is this to pack than a standard folding box?

Noticeably faster. Because the corners are pre-glued, the operator simply pulls the side walls upward, and the front walls snap into place automatically. There are no tabs to tuck or panels to roll over.

Inserts

Does it work well with custom inserts?

Yes. The double-thick walls provide a very stable, rigid perimeter that holds die-cut paperboard or molded inserts securely in place, making it useful for multi-item gift kits.

Production

Can I use this style for very short production runs?

It depends on your assembly budget. The 4-corner gluing relies on specific machine setup, which is more efficient for medium-to-high volumes. For short runs, manual gluing or a different unglued style might be more practical.

Closure

How does the lid stay closed?

It relies on a friction fit over the base walls. For retail or hand-delivery, this is often enough, but for transit, it usually needs a clear wafer seal, label, or an outer shipping box.
