ECMA X23

Reduced-Flap Locking Closure for Folding Cartons

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Tongue-and-slit locking top for secure retail display
  • Shortened dust flaps prevent interference with the closure
  • Delivered flat and opened into a rectangular tube for loading

About this product

ECMA X23 specifies a reclosable opening with reduced flaps and a locking device. It is a Group X feature used with a folding-carton design. The illustrated carton shows one locking-top arrangement.

Its locking tab adds retention beyond a simple friction tuck while keeping the opening reclosable.

Common uses

  • Dry foods and snacks
  • Cosmetics and personal care
  • Light hardware and parts
  • Multi-use consumer goods

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for paperboard preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail and Multi-Use Applications

Multi-Use Consumer Goods

Products that are accessed repeatedly, such as dry foods, hardware assortments, or personal care items, benefit from the locking tab. The tongue-and-slit design resists the tearing and wear that often occurs with standard tuck flaps, keeping the package looking neat over its lifespan.

Retail Shelf Display

The positive lock prevents the top flap from bowing or opening unexpectedly on the shelf, ensuring a clean, uniform presentation. The front panel remains flat and unobstructed, providing a clear surface for branding and product information.

Hardware and Small Parts Kits

For items like fasteners, craft supplies, or hobby kits, the locking tab provides a more positive hold than a friction tuck. This helps keep small components contained when the carton is stored in a drawer or toolbox.

Premium Personal Care

The precise die-cut lock adds a tactile element of quality when the user opens and closes the package. It provides a secure feel for lightweight bottles, tubes, or jars without requiring clear wafer seals for closure.

Product Types That Benefit from a Locking Tab

Dry Foods and Confectionery

Useful for bagged snacks, loose candies, or dry mixes where the consumer needs to reseal the box after the initial opening. The locking tab keeps the top secure without requiring additional clips or stickers.

Cosmetics and Pharmacy

Provides a premium, secure feel for lightweight bottles, tubes, or jars. The precise die-cut lock adds a tactile element of quality when the user opens and closes the package.

Fasteners and DIY Components

Screws, nails, and small parts are often kept in their original packaging for months. The locking tab withstands repeated access better than a standard tuck flap, which can tear at the corners over time.

When to Consider a Standard Tuck or Outer Shipper

Parcel Shipping and Outer Packaging

The friction lock on the X23 is designed for retail handling, not the impacts of courier networks. If the carton will be shipped directly to a consumer, it often requires an outer corrugated mailer or security tape to prevent accidental opening.

Automated Packing Lines

While the side seam is glued automatically by the manufacturer, inserting the locking tab into the slit often requires manual labor or specialized robotic tooling. If your packing line relies on standard automated tucking, a conventional reverse or straight tuck carton may be easier to run.

Board Choice and Base Closure Options

Board Caliper and Material

The performance of the lock depends heavily on the board. Solid Bleached Board or Folding Boxboard provides the right balance of stiffness and flexibility. If the board is too thin, the tab may bend during insertion; if it is too thick, the slit clearances must be carefully adjusted.

Bottom Closure Style

The X23 defines the top locking mechanism, but the bottom can be configured to match your packing process. Options include a standard tuck for lightweight items, a snap-lock for faster manual setup, or an auto-bottom for the quickest erection and heavier payloads.

Paperboard Grain Direction

For the lock to align perfectly, the main panels must remain flat. Specifying the correct grain direction prevents the front and back panels from bowing, ensuring the tongue meets the slit accurately.

Surface Finishes and Coatings

Heavy varnishes or laminations applied over the locking slit can change the friction of the closure. Discuss any planned coatings to ensure the tab still slides in smoothly without cracking the finish.

Adjusting the Lock and Dimensions

Tab and Slit Dimensions

The length and depth of the locking tongue, as well as the width of the receiving slit, can be adjusted. A deeper tab provides a stronger hold but requires more effort to open, while a wider tab distributes wear over a larger area of the front panel.

Dust Flap Clearance

The side dust flaps are intentionally reduced so they do not block the slit when folded inward. Their exact length can be tuned to maximize top-panel support while maintaining clear access for the locking tab.

Tongue Taper Angle

The sides of the locking tab are tapered to guide it into the slit. This angle can be modified to make manual insertion faster or to increase the holding friction once the tab is fully seated.

Board and packing details

Artwork Placement Around the Slit

The receiving slit is a physical cut in the front panel. Critical text, logos, or barcodes should be routed away from this top center area to ensure they are not interrupted by the cut or covered by the locking tab.

Additional notes

Closure durability and repeated use

The primary advantage of this closure is its durability over multiple openings. Unlike standard tuck flaps that can tear at the corners, the localized tab and slit handle repeated friction well when paired with a strong paperboard.

Related Carton Styles

ECMA A20: Standard Reverse Tuck Carton

A simpler closure for high-speed automated packing lines without the need for a localized locking tab.

ECMA A60: Auto-Bottom Carton

Rapid manual setup is the primary goal, pairing a fast-erecting base with a standard top closure.

FAQs

Closure and Handling

Does the locking tab require tape or glue?

The top closure relies entirely on the friction fit between the paperboard tongue and the die-cut slit. However, if the carton is used for parcel shipping, the top may need security tape or the carton should be placed inside an outer shipper.

Is this carton tamper-evident?

The tongue-and-slit lock can be opened and closed multiple times without leaving visible damage. If tamper evidence is required, a clear wafer seal or perforated label must be applied over the closure.

Product Fit

Can this carton hold heavy items?

The vertical walls provide good stacking strength, but the top closure is not designed to bear heavy internal loads if the carton is inverted. The overall weight capacity depends more on the chosen bottom closure and the board thickness.

Production and Packing

Are the side dust flaps supposed to be short?

The dust flaps are intentionally reduced so they sit clear of the central locking mechanism. If they were full length, they would block the tongue from entering the slit.

Materials

Can this be made from corrugated board?

It is generally a poor fit for standard corrugated board. The thickness of the flutes makes the tongue-and-slit mechanism clunky and prone to crushing during insertion. It performs well in solid paperboard.

Production and Packing

Is this carton delivered flat?

The side seam is glued during manufacturing, and the cartons are delivered flat. They are easily opened into a rectangular tube for loading.

Materials

What happens if the paperboard is too thin?

If the board lacks stiffness, the locking tongue can bend or crumple during insertion. This makes it difficult to close the carton securely and reduces the lifespan of the reusable lock.

Design and Print

Does the locking slit interfere with front panel artwork?

The slit is a physical cut in the paperboard, and the locking tab rests inside it. Critical text or logos should be routed away from the top center of the front panel to avoid being cut or obscured.
