EVC62031

Multi-Shelf Floor Display with Angled Back

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Freestanding multi-shelf retail display
Angled back and central spine for stability
Flat-packed kit requires manual tab-and-slot assembly

About this product

The EVC62031 is a freestanding corrugated floor display designed for retail environments. It features an angled rear wall and a central vertical divider that work together to support multiple product shelves.

Delivered as a flat-packed kit of interlocking parts, this display requires no glue for assembly. It relies on mechanical tab-and-slot connections and locking pegs, making it a strong candidate for co-packer fulfillment or in-store setup.

Common uses

End-cap retail promotions
Freestanding aisle displays
Co-packer loaded pallet displays
Seasonal product rollouts

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Overall width

Overall depth

Overall height

Number of shelves

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

How heavy is the product on each shelf?

How should the display be printed?

How will the display be packed and shipped to stores?

Do you need a custom shape for the top header?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Retail and promotional display roles

Freestanding aisle placement

The angled rear wall and central spine provide stability, allowing the display to stand independently in retail aisles without needing a supporting wall.

End-cap retail promotions

The multi-tiered shelves offer organized presentation for lightweight to medium-weight goods, making it suitable for end-cap promotional rollouts.

High-visibility point of purchase

The V-shaped back panel naturally draws attention from multiple angles, making it useful for central store locations where shoppers approach from different directions.

Seasonal product rollouts

Because the entire unit ships flat and requires no permanent fixtures, it serves well for temporary seasonal campaigns that need a dedicated, branded footprint.

Fulfillment and distribution paths

Co-packer assembly and pallet shipping

Because the display consists of at least eight distinct component types, co-packers often assemble the unit, load the product, and ship it to retail on a pallet with an outer protective shroud.

Flat-pack distribution to retail stores

The kit can be shipped flat directly to retail locations. However, the multi-part tab-and-slot assembly requires clear instructions and dedicated staff time, which should be factored into the rollout plan.

Multi-SKU merchandising programs

The separated shelves allow brands to group different product variations or complementary items on a single freestanding unit, keeping the presentation organized.

When to evaluate alternative displays

Flush wall placement requirements

If the display must sit completely flush against a flat wall, a standard straight-backed floor display is a better fit than this angled-back design.

Constrained retail assembly time

If store staff have minimal time for assembly, consider a pre-glued, pop-up display style instead of this multi-component interlocking kit.

Board, print, and kitting choices

Board grade selection for spine and shelves

This display often uses a heavier board for the load-bearing rear wall and central divider, while using a lighter board for the shelves. The cutting dies must be precisely matched to these chosen thicknesses to ensure the slots fit correctly.

Print surface planning for angled panels

The angled rear wall and the folded shelves often expose both their inner and outer surfaces to the consumer. Review the artwork to determine if two-sided printing is required.

Component kitting and master packing

The display requires multiple parts, including small locking pegs. Decide how these components will be collated, nested, and packed into a master shipper to ensure no pieces are lost during transit.

Shelf capacity and product weight

Determine the exact weight of the goods per tier. This dictates whether the shelves need a thicker flute profile or if the central spine requires reinforcement to prevent sagging over time.

Adjusting shelves, headers, and spacing

Shelf count and vertical spacing

The number of shelves and the vertical distance between them can be adjusted to accommodate different product heights.

Shelf depth and cantilever stress

Shelf dimensions can be modified, but wider or deeper shelves increase cantilever stress and may require thicker board to prevent sagging.

Header panel shape and branding

The top header panel can be cut to custom profiles to match brand logos or campaign themes, provided the base tab still aligns with the rear wall slots.

Packing details

Locking pegs and shelf retention

Small corrugated locking pegs are inserted into the protruding shelf tabs at the back of the display. These are critical for preventing the shelves from pulling out horizontally.

Additional notes

Physical load testing

Always request a physical prototype to test with your actual product weight. This confirms that the shelf tabs and central divider can support the load without tearing or buckling.

Master shipper sizing

The flat components must be packed into a master shipping carton. The size of the largest component (usually the rear wall or divider) will dictate the footprint of this outer box.

FAQs

Does this display require glue or tape to assemble?

No. The entire display relies on mechanical tab-and-slot interlocking and small corrugated locking pegs. It is designed to be assembled entirely by hand.

Is this suitable for store staff to set up?

It can be, but it requires following a multi-step sequence to connect the base, rear wall, divider, and multiple shelves. If retail labor is highly constrained, a co-packer assembly or a simpler pop-up design may be less risky.

How much weight can the shelves hold?

Weight capacity depends entirely on the chosen board grade and the dimensions of the shelves. The central vertical divider helps prevent sagging, but physical load testing with your actual product is always required before a full production run.

Can the assembled display be shipped via parcel networks?

Fully assembled floor displays are generally not suited for loose parcel shipping due to their size and exposed shelves. They are typically shipped flat in a master carton, or assembled and shipped on a pallet with a protective outer shroud.

Where can graphics be applied?

Graphics are typically applied to the header, the angled rear wall, the shelf lips, and the base pedestal. Because of the folding sequence, some components may benefit from two-sided printing.

Why does this display use different board thicknesses?

To balance cost and performance, the central spine (rear wall and divider) often uses a thicker, stronger board, while the shelves use a lighter board. The factory must adjust the slot widths in the cutting dies to match these exact material choices.

Can the header panel be cut to a custom shape?

Yes, the header panel can be die-cut to match specific brand logos or campaign shapes, as long as the connecting tab remains compatible with the rear wall slots.

How are the locking pegs managed during shipping?

Because the locking pegs are small, loose components, they are typically nested within the waste areas of larger panels or bagged together inside the master carton to ensure they arrive safely with the rest of the kit.
