ECMA E14.11.00.00

Top-Clip Can Carrier

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Unitizes a single row of cans using minimal material
  • Locks mechanically under the can rim without adhesive
  • Leaves product bodies fully visible for retail display

About this product

The E14.11.00.00 is a minimalist, one-piece paperboard carrier designed to unitize a single row of cylindrical products, such as beverage cans or food tins. Instead of wrapping around the entire product or using adhesive, it sits on top of the row and uses angled side panels with specialized cutouts to grip the underside of the can rims.

Because it relies entirely on mechanical tension and the physical strength of the board to lift the products, the locking cutouts must be precisely matched to the exact chime profile of the cans.

Common uses

  • Beverage cans
  • Food tins
  • Pet food cans
  • Promotional multipacks

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for paperboard preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Multipacks And Beverage Grouping

Retail beverage multipacks

This carrier excels at grouping three, four, or more cans into a single retail unit while using less board than a fully enclosed carton. It provides a continuous top panel for branding and barcode scanning while leaving the primary can graphics completely visible on the shelf.

Canned food grouping

For soups, beans, or pet food, this top-clip style keeps multiple tins together for promotional sales or bulk purchasing without hiding the individual product labels.

Promotional or trial packs

When introducing a new flavor or offering a limited-time bundle, this carrier provides a quick way to group a single row of cans while offering a dedicated billboard on top for the promotional message.

Minimalist retail display

Brands looking to highlight the primary container's artwork often choose this style because it covers only the top rim, allowing the full can body to remain visible to the shopper.

Beverage And Canned Goods Sectors

Beverage brands and breweries

Craft brewers and beverage companies use this top-clip to group cans for retail shelves, offering a paperboard alternative to traditional plastic rings.

Canned goods producers

Food manufacturers use this clip to create multi-packs of canned vegetables, soups, or pet food, reducing the need for shrink film or fully enclosed cartons.

Retailers seeking plastic alternatives

Retail channels focused on reducing plastic packaging often prefer paperboard top-clips, provided the board strength and application method align with the packing setup.

When To Consider A Full Wrap Or Vertical Clip

Heavy loads or rough transit routes

Because the entire weight of the multipack is suspended from the small paperboard cutouts gripping the can rims, this carrier is not intended as a standalone shipping container. If the products will face rough individual handling through parcel networks, or if the cans require protection from denting, a fully enclosed carton or a corrugated master shipper is worth comparing.

Need for more branding surface

If the top panel does not provide enough space for nutritional information, barcodes, and marketing copy, a glued wrap-around carrier (E14.20.00.00) offers more printable surface area.

Board Strength And Application Method

Matching the chime and specifying the board

The most critical decision for this carrier is the exact geometry of the target can. The cutouts and internal locking tongues must be calibrated to the specific diameter and rim (chime) profile of the product. Additionally, because the locks bear the lifting load, the board must have high tear resistance.

Application method

While this carrier can be applied by hand for small sample runs, the simultaneous downward and inward force required to snap all locks over the can rims makes manual application inefficient for production volumes. High-volume packing lines often use specialized automated applicator heads.

Can spacing and display preferences

The template can be adjusted to change the spacing between individual cans in the row, accommodating different product diameters or specific retail shelf-space requirements.

Grain direction and tear resistance

Grain direction must be specified to run perpendicular to the main folding creases to maintain locking tension and prevent the carrier from bowing under the weight of the cans.

Tuning The Lock And Tension

Adjusting the bevel angle

The inward angle of the side panels determines how tightly the carrier grips the cans. A steeper angle increases locking tension but requires more force during application.

Tuning the lock hole and tongue size

The internal tongues and cutouts can be resized to match different can chimes, ensuring a tight mechanical lock that prevents the cans from slipping out.

Changing the can spacing

The gap between the cutouts can be widened or narrowed to adjust how closely the cans sit next to each other in the row.

Board and packing details

Application machinery considerations

Manual application is possible for prototyping or very small batches, but it is difficult to apply the even, simultaneous pressure needed to engage all the locks at once. Production runs often use automated applicator machinery to maintain speed and consistency.

Additional notes

Grain direction and locking strength

The grain direction of the paperboard is critical for this carrier. It must run perpendicular to the main longitudinal creases to prevent the carrier from bowing and to ensure the locking tabs have maximum strength.

Related Multipack Styles

FAQs

Product Fit

Can this carrier be used for any cylindrical product?

It requires a rigid, protruding top rim or chime to function. The internal paperboard tongues must have a physical ledge to catch underneath. It is not suitable for smooth-sided cylinders without a distinct rim.

Production and Packing

Is this carrier easy to apply by hand?

Manual application is possible for prototyping or very small batches, but it is difficult to apply the even, simultaneous pressure needed to engage all the locks at once. Production runs often use automated applicator machinery.

Materials

What type of paperboard makes sense for this clip?

Because the small locking tabs bear the entire weight of the suspended cans, high tear-strength materials like Solid Bleached Board (SBB) or Kraft-backed boards are often considered. Standard folding boxboard may tear under heavy loads.

Shipping

Can I ship these multipacks through a parcel network?

The carrier unitizes the cans for retail display and easy carrying, but it leaves the can bodies exposed to denting and the locks can disengage under rough handling. They typically need to be packed inside a master corrugated shipper for transit.

Design

Can we add finger holes for carrying?

Adding finger holes to the top panel is possible, but it must be done carefully so it does not compromise the strength of the board spanning between the cans.

Prototyping

What is needed to start a prototype?

The exact physical dimensions of the can, particularly the diameter and the precise profile of the top rim (chime), are necessary to test the locking tension. Physical samples of the cans are highly recommended.

Sustainability

Does this help reduce plastic packaging?

Yes, this paperboard carrier is often used as an alternative to plastic multipack rings or shrink film, provided the board strength and application method align with the packing setup.

Storage

How are these delivered and stored?

These carriers are delivered flat and require no pre-gluing, making them highly space-efficient to store before they are applied to the cans.
