ECMA E21.20.00.00

Wrap-Around Bottle Carrier with Closed Sides

  • Available in a wide range of custom configurations & material selection.
  • Order 1 sample. Or order 100K+ units. Or anything in between.
  • Affordable delivery across North America.
  • Design support, warehousing, testing, assembly available.
  • Widest machinery capability in America via 30+ specialist partner plants.
Get pricing

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

  • Formed and glued on automated wrap-around equipment
  • Closed side panels provide large retail branding space
  • Neck and heel cutouts lock bottles in place

About this product

This wrap-around sleeve unitizes a single row of bottles into a tight multipack. Delivered flat, the board is formed directly around the product on the filling line. Specialized cutouts grip the bottle necks, while bottom tabs cup the bases so the bottles do not slide out the open ends.

By keeping the side panels closed, this package provides a large, uninterrupted surface for retail branding while leaving the caps visible. Because the carton relies on the bottles for its internal shape, it relies on precise matching to the physical bottle profile and is intended for automated wrap-around packing.

Common uses

  • Craft beer and cider multipacks
  • Ready-to-drink cocktail bundling
  • Premium sauce and condiment retail packs
  • Health and wellness drinks

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Best Price Guarantee

Already have a packaging quote? Let us beat it.

Send us the quote you have. We will beat it for the same specifications, quantity, and delivery requirements.

Upload a competing quote

Free quote review. No obligation.

30+specialist partner plants

We supply through the plant best suited to your price, material, production, and delivery requirements.

Why we can beat a lower quote

30+ plants give us more ways to lower the price.

Each plant has different machinery, material costs, order minimums, and freight rates. Our buying volume helps us secure better pricing. We then quote through the plant that gives you the lowest total price for your requirements.

Send us your current quote. Watch us beat it.

Attach it to the quote form or email it to us. We'll review it free and send you our price.

Upload a competing quoteinfo@herculeindustrial.com
Best Price Guarantee terms

To qualify, send a written supplier quote dated within the past 30 days and addressed to your company. It must cover the same dimensions, construction, material, print, finish, quantity, tooling, freight, delivery date, and delivery location. The guarantee does not cover taxes, expired quotes, liquidation or clearance sales, or obvious pricing errors.

Files or competing quote (optional)
Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity
Units
Materials and print
Add details for paperboard preference
Add details for print and artwork
Current box or specs
Add details for do you have a current box, spec, or target sample?

Retail Multipacks and Beverage Bundling

Retail beverage multipacks

Used for bundling craft beer, cider, and ready-to-drink cocktails in single rows. The closed sides offer high branding visibility, while the open ends and top cutouts keep the primary bottle design exposed.

Premium sauce and condiment bundling

Groups glass jars or bottles for club-store sales or promotional retail displays, keeping the heavy containers locked together without hiding the product.

Health and wellness drinks

Bundles kombucha, energy shots, or specialty juices in glass bottles. The tight wrap prevents the bottles from shifting during retail handling.

Specialty oils and syrups

Creates retail-ready sets for olive oils or flavored syrups, using the closed side panels to tell a unified brand story across multiple bottles.

High-Volume Beverage and Sauce Production

Automated filling facilities

This format is shipped as a flat, unglued blank. It makes sense when the packing line has automated wrap-around equipment that can fold the board over the bottles and apply adhesive to the bottom seam in one continuous motion.

Retail and club store displays

When the primary goal is shelf impact, the closed side panels provide a much larger continuous canvas for artwork compared to open-sided carriers or plastic rings.

Beverage brand owners

For brands looking to move away from plastic rings, this paperboard sleeve can support plastic-reduction goals when the buyer's material route supports it, while still securely unitizing the bottles.

When to Consider Different Multipack Styles

Hand-packing operations

Wrapping and gluing this sleeve tightly by hand is inefficient. If the packing process is manual, a pre-glued auto-bottom carrier or a basket-style carton is usually a better choice.

Need for a carrying feature

If consumers need to carry heavier multipacks long distances, compare this to a wrap-around sleeve that includes an integrated top handle.

Board, Moisture, and Machinery Alignment

Board strength and moisture resistance

Because the bottom seam and top cutouts bear the lifting load, the board needs high tear resistance. If the bottles will be refrigerated, moisture-resistant board helps prevent the carton from failing due to condensation.

Varnish-free glue zones

The bottom flaps overlap and are glued together beneath the bottles. The artwork should leave these overlapping areas free of ink and varnish so the adhesive can form a secure bond.

Exact bottle profiling

The cutouts, shoulder angles, and overall length should be mapped to the physical bottle. Even minor changes in bottle shape mean tuning the template to prevent slipping or tearing.

Packing line compatibility

The width of the bottom overlapping flaps and the overall blank size should match the specific tolerances and glue nozzle placement of the automated wrap-around equipment.

Tuning the Sleeve to the Bottle

Neck hole and radial slit sizing

The top cutouts need to be wide enough to clear the bottle cap, while the surrounding radial slits flex to grip the narrower neck, preventing the bottles from shifting.

Heel cutout profiling

The cutouts and locking tongues on the bottom flaps should be matched exactly to the chamfer or curve at the base of the bottle to keep the product from sliding out the open ends.

Bottom seam overlap width

The overlapping flaps on the bottom can be adjusted to provide enough surface area for the adhesive, depending on the compression limits of the packing machinery.

Board and packing details

Grain direction and wrapping

The board's grain direction is typically specified to run horizontally across the blank, ensuring the side panels wrap cleanly around the bottles without bowing.

Overlap and Flap Adjustments

Fixed bottom overlap (.a variant)

Enforces a specific, narrow overlap for the bottom glue flaps, which can reduce board usage for cartoning setups that do not need full-width flap overlaps.

Additional notes

Exact bottle dimensions

The cutouts, shoulder angles, and overall length should be mapped to the physical bottle. Even minor changes in bottle shape mean tuning the template to prevent slipping or tearing.

Related Wrap-Around Carriers

E21.22.00.00: Wrap-around with carrying handle

Adds a top handle for consumer convenience on heavier multipacks.

E21.21.00.00: Open-sided wrap-around carrier

Uses narrower side panels to expose more of the bottle body, reducing overall board usage.

FAQs

Packing and Assembly

Can this sleeve be assembled by hand?

Hand assembly is inefficient because the flat blank is pulled tightly around the bottles and glued simultaneously. It is intended for automated wrap-around equipment.

Product Fit

Will this hold heavy glass bottles securely?

It can, provided the board has high tear resistance and the heel cutouts are profiled exactly to the bottle's base. The cutouts cup the bottom of the glass to prevent lateral sliding.

Shipping and Route

Can this multipack be shipped through parcel networks?

Because the glass necks are exposed and the ends are open, this is a primary retail package. It usually needs a master corrugated tray or shipper for transit and parcel delivery.

Materials

What board is best for refrigerated beverages?

Cold bottles generate condensation, which weakens standard paperboard. Moisture-resistant or treated board is usually needed to maintain the carton's strength in cold-chain environments.

Closure

How is the bottom of the sleeve sealed?

The two bottom flaps overlap beneath the bottles. The automated packing line applies adhesive to this overlap and compresses it to form the final sleeve.

Product Fit

Why are there small slits around the top holes?

The slits allow the wider bottle cap to push through during packing. Once the cap clears, the board flexes back to grip the narrower neck, keeping the bottle stable.

Comparison

When should I choose an open-sided carrier instead?

An open-sided carrier uses narrower side panels, which exposes more of the bottle body and reduces overall board usage. It is a good choice when maximizing the visibility of the primary bottle label is more important than having a large carton billboard.

Prototyping

Can I test this design before ordering a full run?

Prototypes can be cut for testing, but manual assembly will not perfectly replicate the tension achieved by a machine. Exact physical bottle samples are usually needed to tune the cutouts before testing.
