ECMA F40.71.00.00

Burger Box Clamshell

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Webbed corners provide natural leak resistance
Delivered flat and opens quickly for fast packing
Sloped walls create a secure friction-fit closure

About this product

The F40.71.00.00 is a widely recognized one-piece clamshell carton, often used as the classic burger box. It features a hinged lid and sloped walls that friction-fit together for quick, secure closure in fast-paced food service environments.

Built with webbed corners that fold inward rather than being cut, this carton creates a continuous barrier to help contain sauces and grease. It is typically pre-glued during conversion and delivered flat, allowing retail staff to push the edges and open it quickly for loading.

Common uses

Fast food burgers and sandwiches
Bakery items and pastries
Food truck takeout
Stadium and event concessions
Fried sides and appetizers

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Length

Width

Depth

Size notes

Quantity notes

Materials and print

Paperboard preference

Add details for paperboard preference

Paperboard details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What type of food will go inside?

Do you need ventilation holes to release steam?

How will these be used in service?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Practical Uses For The Clamshell Carton

Quick-Service Restaurant (QSR) Takeout

The one-piece construction and fast assembly make this carton a strong fit for high-speed food lines. The hinged lid flips closed in a single motion, keeping burgers, sandwiches, or sides hot and protected during handoff.

Bakery And Pastry Protection

For delicate baked goods, the rigid sloped walls prevent crushing when stacked in a larger takeout bag. The friction-fit lid keeps the contents secure without requiring tape or stickers.

Food Truck And Concession Sales

The flat-shipping nature of this carton saves valuable storage space in mobile or temporary kitchens. Staff can quickly erect the boxes as orders come in, maintaining a fast service pace.

Fried Sides And Appetizers

When coated appropriately, the webbed corners contain grease from fried foods. The sloped walls also allow for easy access to the food once the lid is opened.

Service Environments And Channels

Repeat Food Service Programs

Because this carton is often pre-glued on automated folder-gluers, it is well-suited for established, repeat programs. The automated production path supports the fast turnover required by quick-service menus.

Local Delivery And Courier Handoff

While the friction fit holds well for local delivery, the carton is not tamper-evident on its own. Delivery operations often pair this box with a custom sticker seal across the front lip to ensure the package remains closed in transit.

Dine-In Presentation

For casual dining, the clamshell can be served open, acting as a tray. The attached lid remains out of the way, and the customer can easily close it if they wish to take leftovers home.

When To Consider A Different Food Carton

Heavy Liquids Or Soups

While the webbed corners resist grease and light sauces, this carton is not a liquid-tight container. For heavy liquids, dedicated soup cups or bowls with sealed plastic lids are worth comparing.

Long-Distance Parcel Shipping

This is a primary food container, not a shipping box. If you are shipping frozen or packaged foods through a courier network, a corrugated outer shipper will be necessary to protect the cartons.

Key Decisions For Production And Performance

Board Grade And Caliper

The board should be thin enough to allow the webbed corners to fold flat without cracking, but rigid enough to support the food. Folding boxboard (FBB) or solid bleached board (SBB) are frequent choices.

Barrier Coatings

To prevent grease or moisture from degrading the paperboard, a food-safe barrier coating is usually discussed. The chosen coating must be compatible with the adhesive used to glue the corners.

Print And Branding Surface

Branding is typically applied to the outside of the carton, particularly the top of the lid. The inside remains unprinted or uses food-contact-safe inks depending on local regulations and the chosen barrier.

Production Route And Order Maturity

Gluing the diagonal webbed corners runs efficiently on automated folder-gluers, making this style a strong fit for established programs. For very short prototype runs, manual gluing of the corners requires more assembly time.

Template Adjustments And Options

Wall Slope (Bevel Angle)

The angle of the trapezoidal walls can be adjusted. A steeper angle makes the box deeper, but very steep angles can complicate the folding of the corner gussets during manufacturing. The typical angle is usually around 110 degrees.

Ventilation Holes

For hot, crispy foods like fries or fried chicken, small vent holes can be added to the lid or back wall to release steam and prevent the food from becoming soggy.

Base And Lid Proportions

The height of the base tray and the lid can be adjusted independently. A deeper base with a shallow lid is common for burgers, while a deeper lid might be used to accommodate taller sandwiches.

Board and packing details

Flat Shipping And Storage

The carton is built to collapse completely flat after the corners are glued. This allows thousands of units to fit on a single pallet, minimizing storage space behind the counter.

Additional notes

Heat retention and condensation

Paperboard clamshells naturally retain heat well. If condensation is a concern for crispy foods, discuss adding steam vents to the template before production.

FAQs

Assembly and Packing

Does this carton require manual folding?

The carton is typically pre-glued at the factory and delivered flat. Retail staff simply push the edges to open the box into its 3D shape before loading the food.

Performance

Does the burger box prevent leaks?

The webbed corners create a continuous barrier that provides excellent resistance to grease and thick sauces. However, it is not meant to hold thin liquids or soups.

Production

How does the production route affect order size?

Gluing the diagonal webbed corners runs efficiently on automated folder-gluers. This production path makes the carton very practical for repeat programs, while very short prototype runs may require manual gluing.

Modifications

Can we add a window to the lid?

A window can be added to the top panel to display the food, though it involves a separate window-patching process during manufacturing and may reduce the overall rigidity of the lid.

Closure

How does the lid stay closed?

The sloped trapezoidal walls of the lid are shaped to friction-fit over the sloped walls of the base. For delivery security, many brands add a tamper-evident sticker over the front edge.

Materials

Can this be made from corrugated board?

Corrugated board is usually too thick for the small webbed corners, causing them to bind or crack when folded flat. Solid paperboard is the typical material for this style.

Shipping

Can I ship this box through the mail?

This is a primary food container, not a shipping box. To send it through a courier network, you will need to place it inside a corrugated outer shipper to protect the carton and its contents.

Inserts

Can inserts be used inside the clamshell?

Yes, greaseproof paper liners or small dividers can be placed inside to separate items like a burger and fries, though the sloped walls mean any rigid insert must be custom-cut to fit the base.
