FEFCO 0351

Self-Locking Octabin Bulk Bin

Available in a wide range of custom configurations & material selection.
Order 1 sample. Or order 100K+ units. Or anything in between.
Affordable delivery across North America.
Design support, warehousing, testing, assembly available.
Widest machinery capability in America via 30+ specialist partner plants.

Get pricing

Free white-glove consultations. Blazing-fast response time. Fast quotes.

Product details

Top highlights

Eight-sided sleeve resists outward bulging from heavy flowable payloads
Top and bottom caps assemble mechanically without tape or adhesive
Roll-over locks are highly sensitive to board thickness and fold memory

About this product

This heavy-duty, three-piece bulk container uses an eight-sided sleeve to resist the massive outward pressure of flowable goods. Instead of relying on tape or metal stitches to form the top and bottom caps, the 0351 uses 180-degree roll-over flaps that lock mechanically into the base, creating a clean, double-walled perimeter.

You trade standard rotary manufacturing and manual folding time for a tape-free cap assembly. Because the tight roll-over locks must fight the natural tension of heavy corrugated board, this style requires precise material matching to ensure the tabs stay secure during transit.

Common uses

Plastic resins and polymer pellets
Frozen vegetables and agricultural bulk
Chemical powders requiring clean-room staging
PET preforms and small industrial components

Get a quote

Share what you know. We'll take it from there. Or email us at info@herculeindustrial.com

Describe your project *

Approximate quantity *

Size if known

Files or competing quote (optional)Drag files here or choose filesAdd drawings, photos, dielines, quotes, specs, or other useful files.Max 5 files, 25 MB total.

Name *

Email *

Phone

Optional

More details

You can skip this whole part, or open a section and answer only what you know.

Size and quantity

Detailed dimensions

Units US customary (inches)Metric

What do your dimensions describe?

Length

Width

Height

Size notes

Quantity notes

Materials and print

Material or strength preference

Add details for material or strength preference

Material or strength details

Print and artwork

Add details for print and artwork

Print, finish, or artwork details

Shipping or storage context

Custom changes or unusual needs

What type of product will go inside?

Will the bin be stored in cold or humid conditions?

Will you use a plastic liner bag inside the bin?

Current box or specs

Do you have a current box, spec, or target sample?

Add details for do you have a current box, spec, or target sample?

Current box, known specs, or current problem

Destination ZIP or region

Company

Any deadline or timing constraint?

Bulk flowable containment and clean-room staging

Plastic resins and granular materials

The octagonal shape distributes outward hoop stress evenly across eight panels, preventing the side walls from bursting when filled with dense, flowable pellets.

Tape-restricted packing environments

Because the top and bottom caps lock mechanically using roll-over flaps and insertion tabs, workers can assemble the lids without introducing adhesives or metal staples to the packing floor.

Heavy industrial components

Beyond flowable powders, the rigid eight-sided sleeve provides extreme vertical stacking strength for heavy metal parts, PET preforms, or dense automotive components.

Agricultural bulk storage

When paired with an internal poly liner, the rigid sleeve safely holds grains, frozen vegetables, or processed foods, keeping the payload stable during long-term cold storage.

Plastics manufacturing, food processing, and industrial export

Chemical and polymer distributors

Moving bulk powders requires a container that will not deform under settling weight. The 0351 provides the necessary radial strength while allowing the caps to be removed and replaced cleanly during batch sampling.

Bulk food processors

Food-safe environments often restrict metal staples. The sleeve joint can be glued rather than stitched, and the self-locking caps eliminate the need for loose tape near the product.

Clean-room manufacturing facilities

Operations that require strict dust and contaminant control benefit from the mechanical cap locks, which avoid the debris and adhesive residue associated with taping large octagonal lids.

When to consider taped caps or rectangular bins

Extreme triple-wall board requirements

If your payload weight demands the thickest available corrugated board, the 180-degree roll-over locks on the 0351 caps will fight the fold and pop open. Consider a standard stitched-cap octabin (FEFCO 0350) for reliable closure with heavy-grade materials.

Solid or stacked payloads

If you are packing heavy but solid items like motors or server racks that do not exert outward fluid pressure, a rectangular heavy-duty bin (FEFCO 0314) is easier to die-cut and wastes less material.

Close variants and lookalike dielines

The closest library neighbors include 0352, 0314, 0350. Use this as a variant check if a buyer brings an old code, sample, or dieline that looks close. The deciding details are usually the lock, slot, closure, wall build, part count, or fold sequence.

Board thickness, lock tension, and sleeve fastening

Sleeve joint fastening

The eight-sided tube requires a manufacturer's joint. You must specify whether this joint should be glued, which is required for food and pharma, or metal-stitched, which is often preferred for maximum industrial tear resistance.

Cap locking tension

The roll-over flaps rely on board memory to stay locked. We must calculate the exact layer step creases based on your chosen board grade so the tabs seat firmly without crushing the inner walls.

Internal liner requirements

Corrugated board is not natively safe for direct food contact or fine powders. You must determine the specifications for the internal gusseted poly liner that will actually hold the payload.

Telescopic clearance

The gap between the inner sleeve and the outer caps can be tightened for a strict friction fit or loosened if workers need to remove the top cap frequently during staging.

Sleeve height, cap depth, and asymmetrical footprints

Asymmetrical pallet matching

While the classic octabin uses eight equal panels, the template can be adjusted with unequal sides to maximize the footprint on rectangular Europallets without overhanging the edges.

Cap depth modifications

The depth of the top and bottom caps can be extended to provide more overlap on the sleeve, increasing the double-wall perimeter strength at the top and bottom of the bin.

Sleeve height adjustments

The central tube can be cut to any height to match your exact volume requirements, ensuring you do not leave dangerous empty headspace above the payload.

Board and packing details

Flatbed die-cutting requirements

Unlike simple slotted boxes, the complex roll-over tabs and lock holes on the caps require jumbo flatbed die-cutting, which demands different production routing than standard rotary manufacturing.

Additional notes

Moisture resistance for marine export

If your bulk goods are traveling by sea freight or sitting in cold storage, the board should be specified with wet-strength kraftliners and water-resistant adhesives to prevent the octagonal walls from softening under high humidity.

FAQs

Payload and filling

How much empty space can we leave at the top of the bin?

Bulk bins should be filled with no more than 10 cm of empty headspace. Excessive empty space allows the flowable payload to shift during transit, which dramatically increases the risk of the bin collapsing or tipping when stacked.

Assembly and labor

Can these bins be erected by automated machinery?

No. The 0351 requires manual, two-hand assembly. Workers must erect the eight-sided tube and independently fold and lock the eight roll-over flaps across the top and bottom caps.

Shipping and route

Does this bin require external strapping?

Yes. While the caps lock their own 3D shape mechanically, they only hold to the central sleeve via a telescopic friction fit. Heavy bulk shipments require external banding to secure the caps to the pallet.

Board and material

Can we use triple-wall corrugated for the self-locking caps?

Usually no. Triple-wall board is too thick and rigid to comfortably make the 180-degree roll-over fold required for the 0351 locks. If you need triple-wall strength, we recommend the 0350 style, which uses taped or stitched cap corners instead.

Inserts and liners

Is the corrugated board safe for direct food contact?

No. When packing bulk foods, grains, or pharmaceutical powders, you must use a large gusseted poly liner inside the octabin to protect the payload from contamination and moisture.

Production path

Why does this style require flatbed die-cutting instead of standard rotary slotting?

The self-locking caps require intricate tabs and slots that must be cut on a jumbo flatbed die-cutter. The extended roll-over flaps also create a massive blank footprint, increasing material waste compared to a standard rectangular box.

Handling and access

Can the top cap be removed and replaced during batch sampling?

Yes. Because the caps are not taped or glued to the sleeve, workers can lift the top cap off to access the poly liner, sample the payload, and replace the cap without destroying the packaging.

Structural mechanics

How does the octagonal shape prevent the box from bursting?

A standard rectangular box concentrates outward fluid pressure at its four corners, causing the flat side panels to bulge. An octabin distributes that same hoop stress across eight shorter panels, keeping the walls rigid under heavy granular loads.
